What is Workflow?

Workflow is a group of instructions/commands to the integrations service in Informatica. The integration service is an entity which reads workflow information from the repository, fetches data from sources and after performing transformation loads it into the target.

Workflow - It defines how to run tasks like session task, command task, email task, etc.

To create a workflow

  1. You first need to create tasks
  2. And then add those tasks to the workflow.

A Workflow is like an empty container, which has the capacity to store an object you want to execute. You add tasks to the workflow that you want to execute. In this tutorial, we are going to do following things in workflow.

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Workflow execution can be done in two ways

  • Sequence : Tasks execute in the order in which they are defined
  • Event based : Tasks gets executed based on the event conditions.

In this Tutorial - you will learn

How to open Workflow Manager

Step1 – In the Informatica Designer, Click on the Workflow manager icon

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 2 – This will open a window of Workflow Manager. Then, in the workflow Manager.

  1. We are going to connect to repository "guru99", so double click on the folder to connect.
  2. Enter user name and password then select "Connect Button".

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 3- In the workflow manager.

  1. Right click on the folder
  2. In the pop up menu, select open option

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

This will open up the workspace of Workflow manager.

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

How to Create Connections for Workflow Manager

To execute any task in workflow manager, you need to create connections. By using these connections, Integration Service connects to different objects.

For Example, in your mapping if you have source table in oracle database, then you will need oracle connection so that integration service can connect to the oracle database to fetch the source data.

Following type of connections can be created in workflow manager.

  • Relational Connection
  • Ftp Connection
  • Queue
  • Application

The choice of connection you will create, will depend on the type of source and target systems you want to connect. More often, you would be using relational connections.

To Create a Relational Connection

Step 1 – In Workflow Manager

  1. Click on the Connection menu
  2. Select Relational Option

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 2 – In the pop up window

  1. Select Oracle in type
  2. Click on the new button

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 3 – In the new window of connection object definition

  1. Enter Connection Name (New Name-guru99)
  2. Enter username
  3. Enter password
  4. Enter connection string
  5. Leave other settings as default and Select OK button

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 4 – You will return on the previous window. Click on the close button.

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Now you are set with the relational connection in workflow manager.

Components of Workflow manager

There are three component tools of workflow manager that helps in creating various objects in workflow manager. These tools are

  • Task Developer
  • Worklet Designer
  • Workflow Designer

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Task Developer – Task developer is a tool with the help of which you can create reusable objects. Reusable object in workflow manager are objects which can be reused in multiple workflows. For Example, if you have created a command task in task developer, then you can reuse this task in any number of workflows.

The role of Workflow designer is to execute the tasks those are added in it. You can add any no of tasks in a workflow.

You can create three types of reusable tasks in task developer.

  • Command task
  • Session task
  • Email task

Command task – A command task is used to execute different windows/unix commands during the execution of the workflow. You can create command task to execute various command based tasks. With help of this task you can execute commands to create files/folders, to delete files/folders, to do ftp of files etc.

Session Task - A session task in Informatica is required to run a mapping.

  • Without a session task, you cannot execute or run a mapping
  • A session task can execute only a single mapping. So, there is a one to one relationship between a mapping and a session
  • A session task is an object with the help of which informatica gets to know how and where to execute a mapping and at which time
  • Sessions cannot be executed independently, a session must be added to a workflow
  • In session object cache properties can be configured and also advanced performance optimization configuration.

Email task - With the help of email task you can send email to defined recipients when the Integration Service runs a workflow. For example, if you want to monitor how long a session takes to complete, you can configure the session to send an email containing the details of session start and end time. Or, if you want the Integration Service to notify you when a workflow completes/fails, you can configure the email task for the same.

How to create command task

Step 1- To create a command task we are going to use Task Developer. In Workflow Manager, open the task developer by clicking on tab "task developer" from the menu.

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 2 – Once task developer is opened up, follow these steps

  1. Select Tasks menu
  2. Select Create option

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 3 – In the create task window

  1. Select command as type of task to create
  2. Enter task name
  3. Select create button

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

This will create command task folder. Now you have to configure the task to add command in it, that we will see in next step.

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 4 – To configure the task, double click on the command task icon and it will open an "edit task window". On the new edit task window

  1. Select the commands menu
  2. Click on the add new command icon
  3. Enter command name
  4. Click on the command icon to add command text

This will open a command editor box.

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 5 – On the command editor box, enter the command "mkdir C:\guru99" (this is the windows command to create a folder named "guru99") and select OK.

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Afther this step you will return to the edit tasks window and you will be able to see the command you added in to the command text box.

Step 6 – Click OK on the edit task window,

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

The command task will be created in the task developer under "Guru99" repository.

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Note – use ctrl+s shortcut to save the changes in repository

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

How to create workflow to execute command task

To execute command taks you have to switch on to workflow designer. A workflow designer is a parent or container object in which you can add multiple tasks and when workflow is executed, all the added tasks will execute. To create a workflow

Step 1 – Open the workflow designer by clicking on workflow designer menu

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 2 – In workflow designer

  1. Select workflows menu
  2. Select create option

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 3 – In create workflow window

  1. Enter workflow name
  2. Select OK Button ( leave other options as default)

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

This will create the workflow.

Naming Convention - Workflow names are prefixed with using 'wkf_', if you have a session named 's_m_employee_detail' then workflow for the same can be named as 'wkf_s_m_employee_detail'.

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

When you create a workflow, it does not consist of any tasks. So, to execute any task in a workflow you have to add task in it.

Step 4 - To add command task that we have created in Task developer to the workflow desinger

  1. In the navigator tree, expand the tasks folder
  2. Drag and drop the command task to workflow designer

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 5 - Select the "link task option" from the toolbox from the top menu. (The link task option links various tasks in a workflow to the start task, so that the order of execution of tasks can be defined).

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 6 – Once you select the link task icon, it will allow you to drag the link between start task and command task. Now select the start task and drag a link to the command task.

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Now you are ready with the workflow having a command task to be executed.

How to execute workflow

Step 1 – To execute the workflow

  1. Select workflows option from the menu
  2. Select start workflow option

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

This will open workflow monitor window and executes the workflow

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Once the workflow is executed, it will execute the command task to create a folder (guru99 folder) in the defined directory.

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Session Task

A session task in Informatica is required to run a mapping.

Without a session task, you cannot execute or run a mapping and a session task can execute only a single mapping. So, there is a one to one relationship between a mapping and a session. A session task is an object with the help of which Informatica gets to know how and where to execute a mapping and at which time. Sessions cannot be executed independently, a session must be added to a workflow. In session object cache properties can be configured and also advanced performance optimization configuration.

How to create a session task.

In this exercise you will create a session task for the mapping "m_emp_emp_target" which you created in the previous article.

Step1 – Open Workflow manager and open task developer

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 2 – Now once the task developer opens, in the workflow manager go to main menu

  1. Click on task menu
  2. Select create option

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

This will open a new window "Create Task"

Step 3 – In the create task window

  1. Select session task as type of task.
  2. Enter name of task.
  3. Click create button

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 4 – A window for selecting the mapping will appear. Select the mapping which you want to associate with this session, for this example select "m_emp_emp_target" mapping and click OK Button.

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 5 – After that, click on "Done" button

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Session object will appear in the task developer

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 6 – In this step you will create a workflow for the session task. Click on the workflow designer icon.

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 7 – In the workflow designer tool

  1. Click on workflow menu
  2. Select create option

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 8 – In the create workflow window

  1. Enter workflow name
  2. Select OK. ( leave other properties as default, no need to change any properties)

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

In workflow manager a start task will appear, it's a starting point of execution of workflow.

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 9 – In workflow manager

  1. Expand the sessions folder under navigation tree.
  2. Drag and drop the session you created in the workflow manager workspace.

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 10 - Click on the link task option in the tool box.

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 11 - Link the start task and session task using the link.

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 12 – Double click on the session object in wokflow manager. It will open a task window to modify the task properties.

Step 13 – In the edit task window

  1. Select mapping tab
  2. Select connection property
  3. Assign the connection to source and target, the connection which we created in early steps.
  4. Select OK Button

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Now your configuration of workflow is complete, and you can execute the workflow.

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

How to add multiple tasks to a start task

The start task is a starting point for the execution of workflow. There are two ways of linking multiple tasks to a start task.

  1. Parallel
  2. Serial

In parallel linking the tasks are linked directly to the start task and all tasks start executing in parallel at same time.

How to add tasks in parallel

Step 1 – In the workflow manager, open the workflow "wkf_run_command"

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 2 – In the workflow, add session task "s_m_emp_emp_target". ( by selecting session and then drag and drop)

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 3 – Select the link task option from the toolbox

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 4 - link the session task to the start task (by clicking on start taks, holding the click and connecting to session task)

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

After linking the session task, the workflow will look like this.

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 5 – Start the workflow and monitor in the workflow monitor.

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

How to add tasks in serial mode

But before we add tasks in serial mode, we have to delete the task that we added to demonstrate parallel execution of task. For that

Step 1 – Open the workflow "w.kf_run_command"

  1. Select the link to the session task.
  2. Select edit option in the menu
  3. Select delete option

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 2 – Confirmation dialogue box will appear in a window, select yes option

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

The link between the start task and session task will be removed.

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 3 – Now again go to top menu and select the link task option from the toolbox

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 4 – link the session task to the command task

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

After linking the workflow will look like this

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 5 - To make the visual appearance of workflow more clear

  1. Right click on wokspace of workflow
  2. Select arrange menu
  3. Select Horizontal option

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

If you start the workflow the command task will execute first and after its execution, session task will start.

Workflow Variable

Workflow variables allows different tasks in a workflow to exchange information with each other and also allows tasks to access certain properties of other tasks in a workflow. For example, to get the current date you can use the inbuilt variable "sysdate".

Most common scenario is when you have multiple tasks in a workflow and in one task you access the variable of another task. For example, if you have two tasks in a workflow and the requirement is to execute the second task only when first task is executed successfully. You can implement such scenario using predefined variable in the workflow.

Implementing the scenario

We had a workflow "wkf_run_command" having tasks added in serial mode. Now we will add a condition to the link between session task and command task, so that, only after the success of command task the session task will be executed.

Step 1 - Open the workflow "wkf_run_command"

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 2 - Double click on the link between session and command task

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

An Expression window will appear

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 3 – Double click the status variable under "cmd_create_folder" menu. A variable "$cmd_create_folder.status" will appear in the editor window on right side.

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 4 - Now we will set the variable "$cmd_create_folder.status" condition to succeeded status . which means when the previous tasks is executed and the execution was success, then only execute the next session task.

  1. Change the variable to "$cmd_create_folder.status=SUCCEEDED" value.
  2. Click OK Button

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

The workflow will look like this

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

When you execute this workflow, the command task executes first and only when it succeeds then only the session task will get executed.

Workflow Parameter

Workflow parameters are those values which remain constant throughout the run. once their value is assigned it remains same. Parameters can be used in workflow properties and their values can be defined in parameter files. For example, instead of using hard coded connection value you can use a parameter/variable in the connection name and value can be defined in the parameter file.

Parameter files are the files in which we define the values of mapping/workflow variables or parameters. There files have the extension of ".par". As a general standard a parameter file is created for a workflow.

Advantages of Parameter file

  • Helps in migration of code from one environment to other
  • Alows easy debugging and testing
  • Values can be modified with ease without change in code

Structure of parameter file

The structure of parameter file

  • [folder_name.WF:Workflow_name]
  • $Parameter_name=Parameter_value

Folder_name is the name of repository folder, workflow name is the name of workflow for which you are creating the parameter file.

We will be creating a parameter file for the database connection "guru99" which we assigned in our early sessions for sources and targets.

How to create parameter file

Step 1 – Create a new empty file (notepad file)

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 2 – In the file enter text as shown in figure

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 3 – Save the file under a folder guru99 at the location "C:\guru99" as "wkf_run_command.par"

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

In the file we have created a parameter "$DBConnection_SRC", we will assign the same to a connection in our workflow.

Step 4- Open the workflow "wkf_run_command"

  1. Select workflows menu
  2. Select edit option

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 5 – This will open up edit workflow window, in this window

  1. Go to properties tab menu
  2. Enter the parameter file name as "c:\guru99\wkf_run_command.par"
  3. Select OK Button

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Now we are done with defining the parameter file content and point it to a workflow.

Next step is to use the parameter in session.

Step 6 - In workflow double click on the session "s_m_emp_emp_target", then

  1. Select mappings tab menu
  2. Select connection property in the left panel
  3. Click on the target connection, which is hardcoded now as "guru99"

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 7 - A connection browser window will appear, in that window

  1. Select the option to use connection variable
  2. Enter connection variable name as "$DBConnection_SRC"
  3. Select Ok Button

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Step 8 – In the edit task window connection variable will appear for the target, Select OK button in the edit task window.

Workflow in Informatica: Create, Task, Parameter, Reusable, Manager

Now we are done with creating parameter for a connection and assigning its value to parameter file.

When we execute the workflow, the workflow picks the parameter file looks for the value of its paramters/variables in the parameter file and takes those values.



YOU MIGHT LIKE:
