TensorFlow Binary Classification: Linear Classifier Example

The two most common supervised learning tasks are linear regression and linear classifier. Linear regression predicts a value while the linear classifier predicts a class. This tutorial is focused on Linear Classifiers.

What is Linear Classifier?

A Linear Classifier in Machine Learning is a method for finding an object’s class based on its characteristics for statistical classification. It makes classification decision based on the value of a linear combination of characteristics of an object. Linear classifier is used in practical problems like document classification and problems having many variables.

Classification problems represent roughly 80 percent of the machine learning task. Classification aims at predicting the probability of each class given a set of inputs. The label (i.e., the dependent variable) is a discrete value, called a class.

1. If the label has only two classes, the learning algorithm is a Binary Classifier.
2. Multiclass classifier tackles labels with more than two classes.

For instance, a typical binary classification problem is to predict the likelihood a customer makes a second purchase. Predict the type of animal displayed on a picture is multiclass classification problem since there are more than two varieties of animal existing.

The theoretical part of this tutorial puts primary focus on the binary class. You will learn more about the multiclass output function in a future tutorial.

How Binary classifier works?

You learned in the previous tutorial that a function is composed of two kinds of variables, a dependent variable and a set of features (independent variables). In the linear regression, a dependent variable is a real number without range. The primary objective is to predict its value by minimizing the mean squared error.

For TensorFlow Binary Classifier, the label can have had two possible integer values. In most case, it is either [0,1] or [1,2]. For instance, the objective is to predict whether a customer will buy a product or not. The label is defined as follow:

• Y = 1 (customer purchased the product)
• Y = 0 (customer does not purchase the product)

The model uses the features X to classify each customer in the most likely class he belongs to, namely, potential buyer or not.

The probability of success is computed with logistic regression. The algorithm will compute a probability based on the feature X and predicts a success when this probability is above 50 percent. More formally, the probability is calculated as shown in the below TensorFlow Binary Classification example:

where 0 is the set of weights, the features and b the bias.

The function can be decomposed into two parts:

• The linear model
• The logistic function

Linear model

You are already familiar with the way the weights are computed. Weights are computed using a dot product: Y is a linear function of all the features x_i. If the model does not have features, the prediction is equal to the bias, b.

The weights indicate the direction of the correlation between the features x_i and the label y. A positive correlation increases the probability of the positive class while a negative correlation leads the probability closer to 0, (i.e., negative class).

The linear model returns only real number, which is inconsistent with the probability measure of range [0,1]. The logistic function is required to convert the linear model output to a probability,

Logistic function

The logistic function, or sigmoid function, has an S-shape and the output of this function is always between 0 and 1.

It is easy to substitute the output of the linear regression into the sigmoid function. It results in a new number with a probability between 0 and 1.

The classifier can transform the probability into a class

• Values between 0 to 0.49 become class 0
• Values between 0.5 to 1 become class 1

How to Measure the performance of Linear Classifier?

Accuracy

The overall performance of a classifier is measured with the accuracy metric. Accuracy collects all the correct values divided by the total number of observations. For instance, an accuracy value of 80 percent means the model is correct in 80 percent of the cases.

You can note a shortcoming with this metric, especially for imbalance class. An imbalance dataset occurs when the number of observations per group is not equal. Let’s say; you try to classify a rare event with a logistic function. Imagine the classifier tries to estimate the death of a patient following a disease. In the data, 5 percent of the patients pass away. You can train a classifier to predict the number of death and use the accuracy metric to evaluate the performances. If the classifier predicts 0 death for the entire dataset, it will be correct in 95 percent of the case.

Confusion matrix

A better way to assess the performance of a classifier is to look at the confusion matrix.

The confusion matrix visualizes the accuracy of a classifier by comparing the actual and predicted classes as shown in the above Linear Classifier example. The binary confusion matrix is composed of squares:

• TP: True Positive: Predicted values correctly predicted as actual positive
• FP: Predicted values incorrectly predicted an actual positive. i.e., Negative values predicted as positive
• FN: False Negative: Positive values predicted as negative
• TN: True Negative: Predicted values correctly predicted as actual negative

From the confusion matrix, it is easy to compare the actual class and predicted class.

Precision and Sensitivity

The confusion matrix provides a good insight into the true positive and false positive. In some cases, it is preferable to have a more concise metric.

Precision

The precision metric shows the accuracy of the positive class. It measures how likely the prediction of the positive class is correct.

The maximum score is 1 when the classifier perfectly classifies all the positive values. Precision alone is not very helpful because it ignores the negative class. The metric is usually paired with Recall metric. Recall is also called sensitivity or true positive rate.

Sensitivity

Sensitivity computes the ratio of positive classes correctly detected. This metric gives how good the model is to recognize a positive class.

Linear Classifier with TensorFlow

For this tutorial, we will use the census dataset. The purpose is to use the variables in the census dataset to predict the income level. Note that the income is a binary variable

• with a value of 1 if the income > 50k
• 0 if income < 50k.

This variable is your label

This dataset includes eight categorical variables:

• workplace
• education
• marital
• occupation
• relationship
• race
• sex
• native_country

moreover, six continuous variables:

• age
• fnlwgt
• education_num
• capital_gain
• capital_loss
• hours_week

Through this TensorFlow Classification example, you will understand how to train linear TensorFlow Classifiers with TensorFlow estimator and how to improve the accuracy metric.

We will proceed as follow:

• Step 1) Import the data
• Step 2) Data Conversion
• Step 3) Train the classifier
• Step 4) Improve the model
• Step 5) Hyperparameter:Lasso & Ridge

Step 1) Import the data

You first import the libraries used during the tutorial.

import tensorflow as tf
import pandas as pd

Next, you import the data from the archive of UCI and defines the columns names. You will use the COLUMNS to name the columns in a pandas data frame.

Note that you will train the classifier using a Pandas dataframe.

## Define path data
COLUMNS = ['age','workclass', 'fnlwgt', 'education', 'education_num', 'marital',
           'occupation', 'relationship', 'race', 'sex', 'capital_gain', 'capital_loss',
           'hours_week', 'native_country', 'label']
PATH = "https://archive.ics.uci.edu/ml/machine-learning-databases/adult/adult.data"
PATH_test = "https://archive.ics.uci.edu/ml/machine-learning-databases/adult/adult.test"

The data stored online are already divided between a train set and test set.

df_train = pd.read_csv(PATH, skipinitialspace=True, names = COLUMNS, index_col=False)
df_test = pd.read_csv(PATH_test,skiprows = 1, skipinitialspace=True, names = COLUMNS, index_col=False)

The train set contains 32,561 observations and the test set 16,281

print(df_train.shape, df_test.shape)
print(df_train.dtypes)
(32561, 15) (16281, 15)
age                int64
workclass         object
fnlwgt             int64
education         object
education_num      int64
marital           object
occupation        object
relationship      object
race              object
sex               object
capital_gain       int64
capital_loss       int64
hours_week         int64
native_country    object
label             object
dtype: object

Tensorflow requires a Boolean value to train the classifier. You need to cast the values from string to integer. The label is store as an object, however, you need to convert it into a numeric value. The code below creates a dictionary with the values to convert and loop over the column item. Note that you perform this operation twice, one for the train test, one for the test set

label = {'<=50K': 0,'>50K': 1}
df_train.label = [label[item] for item in df_train.label]
label_t = {'<=50K.': 0,'>50K.': 1}
df_test.label = [label_t[item] for item in df_test.label]

In the train data, there are 24,720 incomes lower than 50k and 7841 above. The ratio is almost the same for the test set. Please refer this tutorial on Facets for more.

print(df_train["label"].value_counts())
### The model will be correct in atleast 70% of the case
print(df_test["label"].value_counts())
## Unbalanced label
print(df_train.dtypes)
0    24720
1     7841
Name: label, dtype: int64
0    12435
1     3846
Name: label, dtype: int64
age                int64
workclass         object
fnlwgt             int64
education         object
education_num      int64
marital           object
occupation        object
relationship      object
race              object
sex               object
capital_gain       int64
capital_loss       int64
hours_week         int64
native_country    object
label              int64
dtype: object

Step 2) Data Conversion

A few steps are required before you train a linear classifier with Tensorflow. You need to prepare the features to include in the model. In the benchmark regression, you will use the original data without applying any transformation.

The estimator needs to have a list of features to train the model. Hence, the column’s data requires to be converted into a tensor.

A good practice is to define two lists of features based on their type and then pass them in the feature_columns of the estimator.

You will begin by converting continuous features, then define a bucket with the categorical data.

The features of the dataset have two formats:

• Integer
• Object

Each feature is listed in the next two variables as per their types.

## Add features to the bucket:
### Define continuous list
CONTI_FEATURES  = ['age', 'fnlwgt','capital_gain', 'education_num', 'capital_loss', 'hours_week']
### Define the categorical list
CATE_FEATURES = ['workclass', 'education', 'marital', 'occupation', 'relationship', 'race', 'sex', 'native_country']

The feature_column is equipped with an object numeric_column to help in the transformation of the continuous variables into tensor. In the code below, you convert all the variables from CONTI_FEATURES into a tensor with a numeric value. This is compulsory to construct the model. All the independent variables need to be converted into the proper type of tensor.

Below we write a code to let you see what is happening behind feature_column.numeric_column. We will print the converted value for age It is for explanatory purpose, hence there is no need to understand the python code. You can refer to the official documentation to understand the codes.

def print_transformation(feature = "age", continuous = True, size = 2):
    #X = fc.numeric_column(feature)
    ## Create feature name
    feature_names = [
    feature]

    ## Create dict with the data
    d = dict(zip(feature_names, [df_train[feature]]))

    ## Convert age
    if continuous == True:
        c = tf.feature_column.numeric_column(feature)
        feature_columns = [c]
    else:
        c = tf.feature_column.categorical_column_with_hash_bucket(feature, hash_bucket_size=size)
        c_indicator = tf.feature_column.indicator_column(c)
        feature_columns = [c_indicator]

## Use input_layer to print the value
    input_layer = tf.feature_column.input_layer(
        features=d,
        feature_columns=feature_columns
        )
    ## Create lookup table
    zero = tf.constant(0, dtype=tf.float32)
    where = tf.not_equal(input_layer, zero)
    ## Return lookup tble
    indices = tf.where(where)
    values = tf.gather_nd(input_layer, indices)
    ## Initiate graph
    sess = tf.Session()
    ## Print value
    print(sess.run(input_layer))
print_transformation(feature = "age", continuous = True)
[[39.]
 [50.]
 [38.]
 ...
 [58.]
 [22.]
 [52.]]

The values are exactly the same as in df_train

continuous_features = [tf.feature_column.numeric_column(k) for k in CONTI_FEATURES]

According to TensorFlow documentation, there are different ways to convert categorical data. If the vocabulary list of a feature is known and does not have plenty of values, it is possible to create the categorical column with categorical_column_with_vocabulary_list. It will assign to all unique vocabulary list an ID.

For instance, if a variable status has three distinct values:

• Husband
• Wife
• Single

Then three ID will be attributed. For instance, Husband will have the ID 1, Wife the ID 2 and so on.

For illustration purpose, you can use this code to convert an object variable to a categorical column in TensorFlow.

The feature sex can only have two value: male or female. When we will convert the feature sex, Tensorflow will create 2 new columns, one for male and one for female. If the sex is equal to male, then the new column male will be equal to 1 and female to 0. This example is displayed in the table below:

rows	sex	after transformation	male	female
1	male	=>	1	0
2	male	=>	1	0
3	female	=>	0	1

In tensorflow:

print_transformation(feature = "sex", continuous = False, size = 2)
[[1. 0.]
 [1. 0.]
 [1. 0.]
 ...
 [0. 1.]
 [1. 0.]
 [0. 1.]]

relationship = tf.feature_column.categorical_column_with_vocabulary_list(
    'relationship', [
        'Husband', 'Not-in-family', 'Wife', 'Own-child', 'Unmarried',
        'Other-relative'])

Below, we added Python code to print the encoding. Again, you don’t need to understand the code, the purpose is to see the transformation

However, a faster way to transform the data is to use the method categorical_column_with_hash_bucket. Altering string variables in a sparse matrix will be useful. A sparse matrix is a matrix with mostly zero. The method takes care of everything. You only need to specify the number of buckets and the key column. The number of buckets is the maximum amount of groups that Tensorflow can create. The key column is simply the name of the column to convert.

In the code below, you create a loop over all the categorical features.

categorical_features = [tf.feature_column.categorical_column_with_hash_bucket(k, hash_bucket_size=1000) for k in CATE_FEATURES]

Step 3) Train the Classifier

TensorFlow currently provides an estimator for the linear regression and linear classification.

• Linear regression: LinearRegressor
• Linear classification: LinearClassifier

The syntax of the linear classifier is the same as in the tutorial on linear regression except for one argument, n_class. You need to define the feature column, the model directory and, compare with the linear regressor; you have the define the number of class. For a logit regression, it the number of class is equal to 2.

The model will compute the weights of the columns contained in continuous_features and categorical_features.

model = tf.estimator.LinearClassifier(
    n_classes = 2,
    model_dir="ongoing/train",
    feature_columns=categorical_features+ continuous_features)

Output

INFO:tensorflow:Using default config.
INFO:tensorflow:Using config: {'_model_dir': 'ongoing/train', '_tf_random_seed': None, '_save_summary_steps': 100, '_save_checkpoints_steps': None, '_save_checkpoints_secs': 600, '_session_config': None, '_keep_checkpoint_max': 5, '_keep_checkpoint_every_n_hours': 10000, '_log_step_count_steps': 100, '_train_distribute': None, '_service': None, '_cluster_spec':
<tensorflow.python.training.server_lib.ClusterSpec object at 0x181f24c898>, '_task_type': 'worker', '_task_id': 0, '_global_id_in_cluster': 0, '_master': '', '_evaluation_master': '', '_is_chief': True, '_num_ps_replicas': 0, '_num_worker_replicas': 1}

Now that the classifier is defined, you can create the input function. The method is the same as in the linear regressor tutorial. Here, you use a batch size of 128 and you shuffle the data.

FEATURES = ['age','workclass', 'fnlwgt', 'education', 'education_num', 'marital', 'occupation', 'relationship', 'race', 'sex', 'capital_gain', 'capital_loss', 'hours_week', 'native_country']
LABEL= 'label'
def get_input_fn(data_set, num_epochs=None, n_batch = 128, shuffle=True):
    return tf.estimator.inputs.pandas_input_fn(
       x=pd.DataFrame({k: data_set[k].values for k in FEATURES}),
       y = pd.Series(data_set[LABEL].values),
       batch_size=n_batch,
       num_epochs=num_epochs,
       shuffle=shuffle)

You create a function with the arguments required by the linear estimator, i.e., number of epochs, number of batches and shuffle the dataset or note. Since you use the Pandas method to pass the data into the model, you need to define the X variables as a pandas data frame. Note that you loop over all the data stored in FEATURES.

Let’s train the model with the object model.train. You use the function previously defined to feed the model with the appropriate values. Note that you set the batch size to 128 and the number of epochs to None. The model will be trained over a thousand steps.

model.train(input_fn=get_input_fn(df_train,
                                      num_epochs=None,
                                      n_batch = 128,
                                      shuffle=False),
                                      steps=1000)


INFO:tensorflow:Calling model_fn.
INFO:tensorflow:Done calling model_fn.
INFO:tensorflow:Create CheckpointSaverHook.
INFO:tensorflow: Graph was finalized.
INFO:tensorflow:Running local_init_op.
INFO:tensorflow:Done running local_init_op.
INFO:tensorflow:Saving checkpoints for 1 into ongoing/train/model.ckpt.
INFO:tensorflow:loss = 88.722855, step = 1
INFO:tensorflow:global_step/sec: 65.8282
INFO:tensorflow:loss = 52583.64, step = 101 (1.528 sec)
INFO:tensorflow:global_step/sec: 118.386
INFO:tensorflow:loss = 25203.816, step = 201 (0.837 sec)
INFO:tensorflow:global_step/sec: 110.542
INFO:tensorflow:loss = 54924.312, step = 301 (0.905 sec)
INFO:tensorflow:global_step/sec: 199.03
INFO:tensorflow:loss = 68509.31, step = 401 (0.502 sec)
INFO:tensorflow:global_step/sec: 167.488
INFO:tensorflow:loss = 9151.754, step = 501 (0.599 sec)
INFO:tensorflow:global_step/sec: 220.155
INFO:tensorflow:loss = 34576.06, step = 601 (0.453 sec)
INFO:tensorflow:global_step/sec: 199.016
INFO:tensorflow:loss = 36047.117, step = 701 (0.503 sec)
INFO:tensorflow:global_step/sec: 197.531
INFO:tensorflow:loss = 22608.148, step = 801 (0.505 sec)
INFO:tensorflow:global_step/sec: 208.479
INFO:tensorflow:loss = 22201.918, step = 901 (0.479 sec)
INFO:tensorflow:Saving checkpoints for 1000 into ongoing/train/model.ckpt.
INFO:tensorflow:Loss for final step: 5444.363.

<tensorflow.python.estimator.canned.linear.LinearClassifier at 0x181f223630>

Note that the loss decreased subsequently during the last 100 steps, i.e., from 901 to 1000.

The final loss after one thousand iterations is 5444. You can estimate your model on the test set and see the performance. To evaluate the performance of your model, you need to use the object evaluate. You feed the model with the test set and set the number of epochs to 1, i.e., the data will go to the model only one time.

model.evaluate(input_fn=get_input_fn(df_test,
                                      num_epochs=1,
                                      n_batch = 128,
                                      shuffle=False),
                                      steps=1000)


INFO:tensorflow:Calling model_fn.
WARNING:tensorflow:Trapezoidal rule is known to produce incorrect PR-AUCs; please switch to "careful_interpolation" instead.
WARNING:tensorflow:Trapezoidal rule is known to produce incorrect PR-AUCs; please switch to "careful_interpolation" instead.
INFO:tensorflow:Done calling model_fn.
INFO:tensorflow:Starting evaluation at 2018-06-02-08:28:22
INFO:tensorflow:Graph was finalized.
INFO:tensorflow:Restoring parameters from ongoing/train/model.ckpt-1000
INFO:tensorflow:Running local_init_op.
INFO:tensorflow:Done running local_init_op.
INFO:tensorflow:Evaluation [100/1000]
INFO:tensorflow:Finished evaluation at 2018-06-02-08:28:23
INFO:tensorflow:Saving dict for global step 1000: accuracy = 0.7615626, accuracy_baseline = 0.76377374, auc = 0.63300294, auc_precision_recall = 0.50891197, average_loss = 47.12155, global_step = 1000, label/mean = 0.23622628, loss = 5993.6406, precision = 0.49401596, prediction/mean = 0.18454961, recall = 0.38637546

{'accuracy': 0.7615626,
 'accuracy_baseline': 0.76377374,
 'auc': 0.63300294,
 'auc_precision_recall': 0.50891197,
 'average_loss': 47.12155,
 'global_step': 1000,
 'label/mean': 0.23622628,
 'loss': 5993.6406,
 'precision': 0.49401596,
 'prediction/mean': 0.18454961,
 'recall': 0.38637546}

TensorFlow returns all the metrics you learnt in the theoretical part. Without surprise, the accuracy is large due to the unbalanced label. Actually, the model performs slightly better than a random guess. Imagine the model predict all household with income lower than 50K, then the model has an accuracy of 70 percent. On a closer analysis, you can see the prediction and recall are quite low.

Step 4) Improve the model

Now that you have a benchmark model, you can try to improve it, that is, increase the accuracy. In the previous tutorial, you learned how to improve the prediction power with an interaction term. In this tutorial, you will revisit this idea by adding a polynomial term to the regression.

Polynomial regression is instrumental when there is non-linearity in the data. There are two ways to capture non-linearity in the data.

• Add polynomial term
• Bucketize the continuous variable into a categorical variable

Polynomial term

From the picture below, you can see what a polynomial regression is. It is an equation with X variables with different power. A second-degree polynomial regression has two variables, X and X squared. Third degree has three variables, X, X²,and X³

Below, we constructed a graph with two variables, X and Y. It is obvious the relationship is not linear. If we add a linear regression, we can see the model is unable to capture the pattern (left picture).

Now, look at the left picture from the picture below, we added five-term to the regression (that is y=x+x²+x³+x⁴+x⁵. The model now captures way better the pattern. This is the power of polynomial regression.

Let’s go back to our example. Age is not in a linear relationship with income. Early age might have a flat income close to zero because children or young people do not work. Then it increases in working age and decreases during retirement. It is typically an Inversed-U shape. One way to capture this pattern is by adding a power two to the regression.

Let’s see if it increases the accuracy.

You need to add this new feature to the dataset and in the list of continuous feature.

You add the new variable in the train and test dataset, so it is more convenient to write a function.

def square_var(df_t, df_te, var_name = 'age'):
    df_t['new'] = df_t[var_name].pow(2)
    df_te['new'] = df_te[var_name].pow(2)
    return df_t, df_te

The function has 3 arguments:

• df_t: define the training set
• df_te: define the test set
• var_name = ‘age’: Define the variable to transform

You can use the object pow(2) to square the variable age. Note that the new variable is named ‘new’

Now that the function square_var is written, you can create the new datasets.

df_train_new, df_test_new = square_var(df_train, df_test, var_name = 'age')

As you can see, the new dataset has one more feature.

print(df_train_new.shape, df_test_new.shape)
(32561, 16) (16281, 16)

The square variable is called new in the dataset. You need to add it to the list of continuous features.

CONTI_FEATURES_NEW  = ['age', 'fnlwgt','capital_gain', 'education_num', 'capital_loss', 'hours_week', 'new']
continuous_features_new = [tf.feature_column.numeric_column(k) for k in CONTI_FEATURES_NEW]

Note that you changed the directory of the Graph. You can’t train different models in the same directory. It means, you need to change the path of the argument model_dir. If you don’t TensorFlow will throw an error.

model_1 = tf.estimator.LinearClassifier(
    model_dir="ongoing/train1",
    feature_columns=categorical_features+ continuous_features_new)

INFO:tensorflow:Using default config.
INFO:tensorflow:Using config: {'_model_dir': 'ongoing/train1', '_tf_random_seed': None, '_save_summary_steps': 100, '_save_checkpoints_steps': None, '_save_checkpoints_secs': 600, '_session_config': None, '_keep_checkpoint_max': 5, '_keep_checkpoint_every_n_hours': 10000, '_log_step_count_steps': 100, '_train_distribute': None, '_service': None, '_cluster_spec':
<tensorflow.python.training.server_lib.ClusterSpec object at 0x1820f04b70>, '_task_type': 'worker', '_task_id': 0, '_global_id_in_cluster': 0, '_master': '', '_evaluation_master': '', '_is_chief': True, '_num_ps_replicas': 0, '_num_worker_replicas': 1}
FEATURES_NEW = ['age','workclass', 'fnlwgt', 'education', 'education_num', 'marital', 'occupation', 'relationship', 'race', 'sex', 'capital_gain', 'capital_loss', 'hours_week', 'native_country', 'new']
def get_input_fn(data_set, num_epochs=None, n_batch = 128, shuffle=True):
    return tf.estimator.inputs.pandas_input_fn(
       x=pd.DataFrame({k: data_set[k].values for k in FEATURES_NEW}),
       y = pd.Series(data_set[LABEL].values),
       batch_size=n_batch,
       num_epochs=num_epochs,
       shuffle=shuffle)

Now that the classifier is designed with the new dataset, you can train and evaluate the model.

model_1.train(input_fn=get_input_fn(df_train,
                                      num_epochs=None,
                                      n_batch = 128,
                                      shuffle=False),
                                      steps=1000)

INFO:tensorflow:Calling model_fn.
INFO:tensorflow:Done calling model_fn.
INFO:tensorflow:Create CheckpointSaverHook.
INFO:tensorflow:Graph was finalized.
INFO:tensorflow:Running local_init_op.
INFO:tensorflow:Done running local_init_op.
INFO:tensorflow:Saving checkpoints for 1 into ongoing/train1/model.ckpt.
INFO:tensorflow:loss = 88.722855, step = 1
INFO:tensorflow:global_step/sec: 81.487
INFO:tensorflow:loss = 70077.66, step = 101 (1.228 sec)
INFO:tensorflow:global_step/sec: 111.169
INFO:tensorflow:loss = 49522.082, step = 201 (0.899 sec)
INFO:tensorflow:global_step/sec: 128.91
INFO:tensorflow:loss = 107120.57, step = 301 (0.776 sec)
INFO:tensorflow:global_step/sec: 132.546
INFO:tensorflow:loss = 12814.152, step = 401 (0.755 sec)
INFO:tensorflow:global_step/sec: 162.194
INFO:tensorflow:loss = 19573.898, step = 501 (0.617 sec)
INFO:tensorflow:global_step/sec: 204.852
INFO:tensorflow:loss = 26381.986, step = 601 (0.488 sec)
INFO:tensorflow:global_step/sec: 188.923
INFO:tensorflow:loss = 23417.719, step = 701 (0.529 sec)
INFO:tensorflow:global_step/sec: 192.041
INFO:tensorflow:loss = 23946.049, step = 801 (0.521 sec)
INFO:tensorflow:global_step/sec: 197.025
INFO:tensorflow:loss = 3309.5786, step = 901 (0.507 sec)
INFO:tensorflow:Saving checkpoints for 1000 into ongoing/train1/model.ckpt.
INFO:tensorflow:Loss for final step: 28861.898.

<tensorflow.python.estimator.canned.linear.LinearClassifier at 0x1820f04c88>

model_1.evaluate(input_fn=get_input_fn(df_test_new,
                                      num_epochs=1,
                                      n_batch = 128,
                                      shuffle=False),
                                      steps=1000)

INFO:tensorflow:Calling model_fn.
WARNING:tensorflow:Trapezoidal rule is known to produce incorrect PR-AUCs; please switch to "careful_interpolation" instead.
WARNING:tensorflow:Trapezoidal rule is known to produce incorrect PR-AUCs; please switch to "careful_interpolation" instead.
INFO:tensorflow:Done calling model_fn.
INFO:tensorflow:Starting evaluation at 2018-06-02-08:28:37
INFO:tensorflow:Graph was finalized.
INFO:tensorflow:Restoring parameters from ongoing/train1/model.ckpt-1000
INFO:tensorflow:Running local_init_op.
INFO:tensorflow:Done running local_init_op.
INFO:tensorflow:Evaluation [100/1000]
INFO:tensorflow:Finished evaluation at 2018-06-02-08:28:39
INFO:tensorflow:Saving dict for global step 1000: accuracy = 0.7944229, accuracy_baseline = 0.76377374, auc = 0.6093755, auc_precision_recall = 0.54885805, average_loss = 111.0046, global_step = 1000, label/mean = 0.23622628, loss = 14119.265, precision = 0.6682401, prediction/mean = 0.09116262, recall = 0.2576703

{'accuracy': 0.7944229,
 'accuracy_baseline': 0.76377374,
 'auc': 0.6093755,
 'auc_precision_recall': 0.54885805,
 'average_loss': 111.0046,
 'global_step': 1000,
 'label/mean': 0.23622628,
 'loss': 14119.265,
 'precision': 0.6682401,
 'prediction/mean': 0.09116262,
 'recall': 0.2576703}

The squared variable improved the accuracy from 0.76 to 0.79. Let’s see if you can do better by combining bucketization and interaction term together.

Bucketization and interaction

As you saw before, a linear classifier is unable to capture the age-income pattern correctly. That is because it learns a single weight for each feature. To make it easier for the classifier, one thing you can do is bucket the feature. Bucketing transforms a numeric feature into several certain ones based on the range it falls into, and each of these new features indicates whether a person’s age falls within that range.

With these new features, the linear model can capture the relationship by learning different weights for each bucket.

In TensorFlow, it is done with bucketized_column. You need to add the range of values in the boundaries.

age = tf.feature_column.numeric_column('age')
age_buckets = tf.feature_column.bucketized_column(
    age, boundaries=[18, 25, 30, 35, 40, 45, 50, 55, 60, 65])

You already know age is non-linear with income. Another way to improve the model is through interaction. In the word of TensorFlow, it is feature crossing. Feature crossing is a way to create new features that are combinations of existing ones, which can be helpful for a linear classifier that can’t model interactions between features.

You can break down age with another feature like education. That is is, some groups are likely to have a high income and others low (Think about the Ph.D. student).

education_x_occupation = [tf.feature_column.crossed_column(
    ['education', 'occupation'], hash_bucket_size=1000)]
age_buckets_x_education_x_occupation = [tf.feature_column.crossed_column(
    [age_buckets, 'education', 'occupation'], hash_bucket_size=1000)]

To create a cross feature column, you use crossed_column with the variables to cross in a bracket. The hash_bucket_size indicates the maximum crossing possibilities. To create interaction between variables (at least one variable needs to be categorical), you can use tf.feature_column.crossed_column. To use this object, you need to add in square bracket the variable to interact and a second argument, the bucket size. The bucket size is the maximum number of group possible within a variable. Here you set it at 1000 as you do not know the exact number of groups

age_buckets needs to be squared before to add it to the feature columns. You also add the new features to the features columns and prepare the estimator

base_columns = [
    age_buckets,
]

model_imp = tf.estimator.LinearClassifier(
    model_dir="ongoing/train3",
    feature_columns=categorical_features+base_columns+education_x_occupation+age_buckets_x_education_x_occupation)

Output

INFO:tensorflow:Using default config.
INFO:tensorflow:Using config: {'_model_dir': 'ongoing/train3', '_tf_random_seed': None, '_save_summary_steps': 100, '_save_checkpoints_steps': None, '_save_checkpoints_secs': 600, '_session_config': None, '_keep_checkpoint_max': 5, '_keep_checkpoint_every_n_hours': 10000, '_log_step_count_steps': 100, '_train_distribute': None, '_service': None, '_cluster_spec': <tensorflow.python.training.server_lib.ClusterSpec object at 0x1823021be0>, '_task_type': 'worker', '_task_id': 0, '_global_id_in_cluster': 0, '_master': '', '_evaluation_master': '', '_is_chief': True, '_num_ps_replicas': 0, '_num_worker_replicas': 1}

FEATURES_imp = ['age','workclass', 'education', 'education_num', 'marital',
                'occupation', 'relationship', 'race', 'sex', 'native_country', 'new']

def get_input_fn(data_set, num_epochs=None, n_batch = 128, shuffle=True):
    return tf.estimator.inputs.pandas_input_fn(
       x=pd.DataFrame({k: data_set[k].values for k in FEATURES_imp}),
       y = pd.Series(data_set[LABEL].values),
       batch_size=n_batch,
       num_epochs=num_epochs,
       shuffle=shuffle)

You are ready to estimate the new model and see if it improves the accuracy.

model_imp.train(input_fn=get_input_fn(df_train_new,
                                      num_epochs=None,
                                      n_batch = 128,
                                      shuffle=False),
                                      steps=1000)


INFO:tensorflow:Calling model_fn.
INFO:tensorflow:Done calling model_fn.
INFO:tensorflow:Create CheckpointSaverHook.
INFO:tensorflow:Graph was finalized.
INFO:tensorflow:Running local_init_op.
INFO:tensorflow:Done running local_init_op.
INFO:tensorflow:Saving checkpoints for 1 into ongoing/train3/model.ckpt.
INFO:tensorflow:loss = 88.722855, step = 1
INFO:tensorflow:global_step/sec: 94.969
INFO:tensorflow:loss = 50.334488, step = 101 (1.054 sec)
INFO:tensorflow:global_step/sec: 242.342
INFO:tensorflow:loss = 56.153225, step = 201 (0.414 sec)
INFO:tensorflow:global_step/sec: 213.686
INFO:tensorflow:loss = 45.792007, step = 301 (0.470 sec)
INFO:tensorflow:global_step/sec: 174.084
INFO:tensorflow:loss = 37.485672, step = 401 (0.572 sec)
INFO:tensorflow:global_step/sec: 191.78
INFO:tensorflow:loss = 56.48449, step = 501 (0.524 sec)
INFO:tensorflow:global_step/sec: 163.436
INFO:tensorflow:loss = 32.528934, step = 601 (0.612 sec)
INFO:tensorflow:global_step/sec: 164.347
INFO:tensorflow:loss = 37.438057, step = 701 (0.607 sec)
INFO:tensorflow:global_step/sec: 154.274
INFO:tensorflow:loss = 61.1075, step = 801 (0.647 sec)
INFO:tensorflow:global_step/sec: 189.14
INFO:tensorflow:loss = 44.69645, step = 901 (0.531 sec)
INFO:tensorflow:Saving checkpoints for 1000 into ongoing/train3/model.ckpt.
INFO:tensorflow:Loss for final step: 44.18133.

<tensorflow.python.estimator.canned.linear.LinearClassifier at 0x1823021cf8>

model_imp.evaluate(input_fn=get_input_fn(df_test_new,
                                      num_epochs=1,
                                      n_batch = 128,
                                      shuffle=False),
                                      steps=1000)


INFO:tensorflow:Calling model_fn.
WARNING:tensorflow:Trapezoidal rule is known to produce incorrect PR-AUCs; please switch to "careful_interpolation" instead.
WARNING:tensorflow:Trapezoidal rule is known to produce incorrect PR-AUCs; please switch to "careful_interpolation" instead.
INFO:tensorflow:Done calling model_fn.
INFO:tensorflow:Starting evaluation at 2018-06-02-08:28:52
INFO:tensorflow:Graph was finalized.
INFO:tensorflow:Restoring parameters from ongoing/train3/model.ckpt-1000
INFO:tensorflow:Running local_init_op.
INFO:tensorflow:Done running local_init_op.
INFO:tensorflow:Evaluation [100/1000]
INFO:tensorflow:Finished evaluation at 2018-06-02-08:28:54
INFO:tensorflow:Saving dict for global step 1000: accuracy = 0.8358209, accuracy_baseline = 0.76377374, auc = 0.88401634, auc_precision_recall = 0.69599575, average_loss = 0.35122654, global_step = 1000, label/mean = 0.23622628, loss = 44.67437, precision = 0.68986726, prediction/mean = 0.23320661, recall = 0.55408216


{'accuracy': 0.8358209,
 'accuracy_baseline': 0.76377374,
 'auc': 0.88401634,
 'auc_precision_recall': 0.69599575,
 'average_loss': 0.35122654,
 'global_step': 1000,
 'label/mean': 0.23622628,
 'loss': 44.67437,
 'precision': 0.68986726,
 'prediction/mean': 0.23320661,
 'recall': 0.55408216}

The new accuracy level is 83.58 percent. It is four percent higher than the previous model.

Finally, you can add a regularization term to prevent overfitting.

Step 5) Hyperparameter:Lasso & Ridge

Your model can suffer from overfitting or underfitting.

• Overfitting: The model is unable to generalize the prediction to new data
• Underfitting: The model is unable to capture the pattern of the data. i.e., linear regression when the data is non-linear

When a model has lots of parameters and a relatively low amount of data, it leads to poor predictions. Imagine, one group only have three observations; the model will compute a weight for this group. The weight is used to make a prediction; if the observations of the test set for this particular group is entirely different from the training set, then the model will make a wrong prediction. During the evaluation with the training set, the accuracy is good, but not good with the test set because the weights computed is not the true one to generalize the pattern. In this case, it does not make a reasonable prediction on unseen data.

To prevent overfitting, regularization gives you the possibilities to control for such complexity and make it more generalizable. There are two regularization techniques:

• L1: Lasso
• L2: Ridge

In TensorFlow, you can add these two hyperparameters in the optimizer. For instance, the higher the hyperparameter L2, the weight tends to be very low and close to zero. The fitted line will be very flat, while an L2 close to zero implies the weights are close to the regular linear regression.

You can try by yourself the different value of the hyperparameters and see if you can increase the accuracy level.

Note that if you change the hyperparameter, you need to delete the folder ongoing/train4 otherwise the model will start with the previously trained model.

Let’s see how is the accuracy with the hype

model_regu = tf.estimator.LinearClassifier(
    model_dir="ongoing/train4", feature_columns=categorical_features+base_columns+education_x_occupation+age_buckets_x_education_x_occupation,
    optimizer=tf.train.FtrlOptimizer(
        learning_rate=0.1,
        l1_regularization_strength=0.9,
        l2_regularization_strength=5))

OUPUT

INFO:tensorflow:Using default config.
INFO:tensorflow:Using config: {'_model_dir': 'ongoing/train4', '_tf_random_seed': None, '_save_summary_steps': 100, '_save_checkpoints_steps': None, '_save_checkpoints_secs': 600, '_session_config': None, '_keep_checkpoint_max': 5, '_keep_checkpoint_every_n_hours': 10000, '_log_step_count_steps': 100, '_train_distribute': None, '_service': None, '_cluster_spec': <tensorflow.python.training.server_lib.ClusterSpec object at 0x1820d9c128>, '_task_type': 'worker', '_task_id': 0, '_global_id_in_cluster': 0, '_master': '', '_evaluation_master': '', '_is_chief': True, '_num_ps_replicas': 0, '_num_worker_replicas': 1}

model_regu.train(input_fn=get_input_fn(df_train_new,
                                      num_epochs=None,
                                      n_batch = 128,
                                      shuffle=False),
                                      steps=1000)

OUPUT

INFO:tensorflow:Calling model_fn.
INFO:tensorflow:Done calling model_fn.
INFO:tensorflow:Create CheckpointSaverHook.
INFO:tensorflow:Graph was finalized.
INFO:tensorflow:Running local_init_op.
INFO:tensorflow:Done running local_init_op.
INFO:tensorflow:Saving checkpoints for 1 into ongoing/train4/model.ckpt.
INFO:tensorflow:loss = 88.722855, step = 1
INFO:tensorflow:global_step/sec: 77.4165
INFO:tensorflow:loss = 50.38778, step = 101 (1.294 sec)
INFO:tensorflow:global_step/sec: 187.889
INFO:tensorflow:loss = 55.38014, step = 201 (0.535 sec)
INFO:tensorflow:global_step/sec: 201.895
INFO:tensorflow:loss = 46.806694, step = 301 (0.491 sec)
INFO:tensorflow:global_step/sec: 217.992
INFO:tensorflow:loss = 38.68271, step = 401 (0.460 sec)
INFO:tensorflow:global_step/sec: 193.676
INFO:tensorflow:loss = 56.99398, step = 501 (0.516 sec)
INFO:tensorflow:global_step/sec: 202.195
INFO:tensorflow:loss = 33.263622, step = 601 (0.497 sec)
INFO:tensorflow:global_step/sec: 216.756
INFO:tensorflow:loss = 37.7902, step = 701 (0.459 sec)
INFO:tensorflow:global_step/sec: 240.215
INFO:tensorflow:loss = 61.732605, step = 801 (0.416 sec)
INFO:tensorflow:global_step/sec: 220.336
INFO:tensorflow:loss = 46.938225, step = 901 (0.456 sec)
INFO:tensorflow:Saving checkpoints for 1000 into ongoing/train4/model.ckpt.
INFO:tensorflow:Loss for final step: 43.4942.


<tensorflow.python.estimator.canned.linear.LinearClassifier at 0x181ff39e48>

model_regu.evaluate(input_fn=get_input_fn(df_test_new,
                                      num_epochs=1,
                                      n_batch = 128,
                                      shuffle=False),
                                      steps=1000)

Output

INFO:tensorflow:Calling model_fn.
WARNING:tensorflow:Trapezoidal rule is known to produce incorrect PR-AUCs; please switch to "careful_interpolation" instead.
WARNING:tensorflow:Trapezoidal rule is known to produce incorrect PR-AUCs; please switch to "careful_interpolation" instead.
INFO:tensorflow:Done calling model_fn.
INFO:tensorflow:Starting evaluation at 2018-06-02-08:29:07
INFO:tensorflow:Graph was finalized.
INFO:tensorflow:Restoring parameters from ongoing/train4/model.ckpt-1000
INFO:tensorflow:Running local_init_op.
INFO:tensorflow:Done running local_init_op.
INFO:tensorflow:Evaluation [100/1000]
INFO:tensorflow:Finished evaluation at 2018-06-02-08:29:09
INFO:tensorflow:Saving dict for global step 1000: accuracy = 0.83833915, accuracy_baseline = 0.76377374, auc = 0.8869794, auc_precision_recall = 0.7014905, average_loss = 0.34691378, global_step = 1000, label/mean = 0.23622628, loss = 44.12581, precision = 0.69720596, prediction/mean = 0.23662092, recall = 0.5579823





{'accuracy': 0.83833915,
 'accuracy_baseline': 0.76377374,
 'auc': 0.8869794,
 'auc_precision_recall': 0.7014905,
 'average_loss': 0.34691378,
 'global_step': 1000,
 'label/mean': 0.23622628,
 'loss': 44.12581,
 'precision': 0.69720596,
 'prediction/mean': 0.23662092,
 'recall': 0.5579823}

With this hyperparameter, you slightly increase the accuracy metrics. In the next tutorial, you will learn how to improve a linear classifier using a kernel method.

Summary

To train a model, you need to:

• Define the features: Independent variables: X
• Define the label: Dependent variable: y
• Construct a train/test set
• Define the initial weight
• Define the loss function: MSE
• Optimize the model: Gradient descent
• Define:
  • Learning rate
  • Number of epoch
  • Batch size
  • Number of class

In this tutorial, you learned how to use the high-level API for a linear regression classifier. You need to define:

1. Feature columns. If continuous: tf.feature_column.numeric_column(). You can populate a list with python list comprehension
2. The estimator: tf.estimator.LinearClassifier(feature_columns, model_dir, n_classes = 2)
3. A function to import the data, the batch size and epoch: input_fn()

After that, you are ready to train, evaluate and make a prediction with train(), evaluate() and predict()

To improve the performance of the model, you can:

• Use polynomial regression
• Interaction term: tf.feature_column.crossed_column
• Add regularization parameter
