TensorFlow Linear Regression with Facet & Interaction Term

TensorFlow Linear Regression

In this tutorial, you will learn how to check the data and prepare it to create a simple linear regression task.

This tutorial is divided into two parts:

• Look for interaction
• Test the model

In the previous tutorial, you used the Boston dataset to estimate the median price of a house. Boston dataset has a small size, with only 506 observations. This dataset is considered as a benchmark to try new linear regression algorithms.

The dataset is composed of:

In this tutorial, we will estimate the median price using a linear regressor, but the focus is on one particular process of machine learning: “data preparation.”

A model generalizes the pattern in the data. To capture such a pattern, you need to find it first. A good practice is to perform a data analysis before running any machine learning algorithm.

Choosing the right features makes all the difference in the success of your model. Imagine you try to estimate the wage of a people, if you do not include the gender as a covariate, you end up with a poor estimate.

Another way to improve the model is to look at the correlation between the independent variable. Back to the example, you can think of education as an excellent candidate to predict the wage but also the occupation. It is fair to say, the occupation depends on the level of education, namely higher education often leads to a better occupation. If we generalize this idea, we can say the correlation between the dependent variable and an explanatory variable can be magnified of yet another explanatory variable.

To capture the limited effect of education on occupation, we can use an interaction term.

If you look at the wage equation, it becomes:

If is positive, then it implies that an additional level of education yields a higher increase in the median value of a house for a high occupation level. In other words, there is an interaction effect between education and occupation.

The same estimator family also powers the linear classifier when the label is a class rather than a price. In this tutorial, we will try to see which variables can be a good candidate for interaction terms. We will test if adding this kind of information leads to better price prediction.

Summary statistics

There are a few steps you can follow before proceeding to the model. As mentioned earlier, the model is a generalization of the data. The best practice is to understand the data first and then make a prediction. If you do not know your data, you have slim chances to improve your model.

As a first step, load the data as a pandas dataframe and create a training set and testing set.

Tips: For this tutorial, you need to have matplotlib and seaborn installed in Python. You can install a Python package on the fly with Jupyter. You Should not do this

!conda install -- yes matplotlib

but

import sys
!{sys.executable} -m pip install matplotlib # Already installed
!{sys.executable} -m pip install seaborn

Note that this step is not necessary if you have matplotlib and seaborn installed.

Matplotlib is the library to create a graph in Python. Seaborn is a statistical visualization library built on top of matplotlib. It provides attractive and beautiful plots.

The code below imports the necessary libraries.

import pandas as pd
from sklearn import datasets
import tensorflow as tf
from sklearn.datasets import load_boston
import numpy as np

The library sklearn includes the Boston dataset. You can call its API to import the data.

Version note: load_boston was deprecated in scikit-learn 1.0 and removed in scikit-learn 1.2 because the dataset encodes a racially loaded feature. On a current install, use fetch_california_housing instead, or load the raw file yourself. The workflow shown below is unchanged; only the loader differs.

boston = load_boston()
df = pd.DataFrame(boston.data)

The feature names are stored in the object feature_names as an array.

boston.feature_names

Output

array(['CRIM', 'ZN', 'INDUS', 'CHAS', 'NOX', 'RM', 'AGE', 'DIS', 'RAD','TAX', 'PTRATIO', 'B', 'LSTAT'], dtype='<U7')

You can rename the columns.

df.columns = boston.feature_names
df['PRICE'] = boston.target
df.head(2)

You convert the variable CHAS as a string variable and label it with yes if CHAS = 1 and no if CHAS = 0

df['CHAS'] = df['CHAS'].map({1:'yes', 0:'no'})
df['CHAS'].head(5)
0    no
1    no
2    no
3    no
4    no
Name: CHAS, dtype: object

With pandas, it is straightforward to split the dataset. You randomly divide the dataset with 80 percent training set and 20 percent testing set. Pandas has a built-in sampling function to split a data frame.

The first parameter frac is a value from 0 to 1. You set it to 0.8 to select randomly 80 percent of the data frame.

random_state fixes the shuffle, so the same rows are returned for everyone.

### Create train/test set
df_train=df.sample(frac=0.8,random_state=200)
df_test=df.drop(df_train.index)

You can get the shape of the data. It should be:

• Train set: 506*0.8 = 405
• Test set: 506*0.2 = 101

print(df_train.shape, df_test.shape)

Output

(405, 14) (101, 14)

df_test.head(5)

Output

Data is messy; it’s often misbalanced and sprinkled with outlier values that throw off the analysis and machine learning training.

The first step to getting the dataset cleaned up is understanding where it needs cleaning. Cleaning up a dataset can be tricky to do, especially in any generalizable manner

The Google Research team has developed a tool for this job called Facets that helps you visualize the data and slice it in all sorts of manners. This is a good starting point to comprehend how the dataset is laid out.

Facets lets you find where the data does not quite look the way you expect.

Except for their web app, Google makes it easy to embed the toolkit into a Jupyter notebook.

There are two parts to Facets:

• Facets Overview
• Facets Deep Dive

Facets Overview

Facets Overview gives an overview of the dataset. Facets Overview splits the columns of the data into rows of salient information showing

1. the percentage of missing observation
2. min and max values
3. statistics like the mean, median, and standard deviation.
4. It also adds a column that shows the percentage of values that are zeroes, which is helpful when most of the values are zeroes.
5. It is possible to see these distributions on the test dataset as well as the training set for each feature. It means you can double-check that the test has a similar distribution to the training data.

This is at least the minimum to do before any machine learning task. With this tool, you do not miss this crucial step, and it highlights some abnormalities.

Facets Deep Dive

Facets Deep Dive is a cool tool. It allows you to gain some clarity on your dataset and zoom all the way in to see an individual piece of data. It means you can facet the data by row and column across any of the features of the dataset.

We will use these two tools with the Boston dataset.

Note: You cannot use Facets Overview and Facets Deep Dive at the same time. You need to clear the notebook first to change the tool.

Before either tool can be used, Facets has to be installed into the notebook environment.

Install Facet

You can use the Facet web app for most of the analysis. In this tutorial, you will see how to use it within a Jupyter Notebook.

First of all, you need to install nbextensions. It is done with this code. You copy and paste the following code in the terminal of your machine.

pip install jupyter_contrib_nbextensions

Right after that, you need to clone the repositories in your computer. You have two choices:

Option 1) Copy and paste this code in the terminal (Recommended)

If you do not have Git installed on your machine, please go to this URL Git for Windows download page and follow the instruction. Once you are done, you can use the git command in the terminal for Mac User or Anaconda prompt for Windows user

git clone https://github.com/PAIR-code/facets

Option 2) Go to the PAIR-code/facets repository and download the repositories.

The repository page above holds the download button used by option 2. If you choose the first option, the file ends up in your download folder. You can either let the file in download or drag it to another path.

You can check where Facets is stored with this command line:

echo `pwd`/`ls facets`

Now that you have located Facets, you need to install it in Jupyter Notebook. You need to set the working directory to the path where facets is located.

Your present working directory and location of Facets zip should be same.

The terminal listing above confirms that facets sits in the current working directory. You need to point the working directory to Facet:

cd facets

To install Facets in Jupyter, you have two options. If you installed Jupyter with Conda for all the users, copy this code:

jupyter nbextension install facets-dist/

Otherwise, use:

jupyter nbextension install facets-dist/ --user

All right, you are all set. Let’s open Facet Overview.

Run Facets Overview in Jupyter

Overview uses a Python script to compute the statistics. You need to import the script called generic_feature_statistics_generator to Jupyter. Don’t worry; the script is located in the facets files.

You need to locate its path. It is easily done. You open facets, open the file facets_overview and then python. Copy the path

After that, go back to Jupyter, and write the following code. Change the path ‘/Users/Thomas/facets/facets_overview/python’ to your path.

# Add the facets overview python code to the python path# Add t
import sys
sys.path.append('/Users/Thomas/facets/facets_overview/python')

You can import the script with the code below.

from generic_feature_statistics_generator import
GenericFeatureStatisticsGenerator

In windows, the same code becomes

import sys
sys.path.append(r"C:\Users\Admin\Anaconda3\facets-master\facets_overview\python")

from generic_feature_statistics_generator import GenericFeatureStatisticsGenerator

To calculate the feature statistics, you need to use the function GenericFeatureStatisticsGenerator(), and you use the object ProtoFromDataFrames. You can pass the data frame in a dictionary. For instance, if we want to create a summary statistic for the train set, we can store the information in a dictionary and use it in the object `ProtoFromDataFrames“

'name': 'train', 'table': df_train

Name is the name of the table displays, and you use the name of the table you want to compute the summary. In your example, the table containing the data is df_train

# Calculate the feature statistics proto from the datasets and stringify it for use in facets overview
import base64

gfsg = GenericFeatureStatisticsGenerator()

proto = gfsg.ProtoFromDataFrames([{'name': 'train', 'table': df_train},
                                  {'name': 'test', 'table': df_test}])

#proto = gfsg.ProtoFromDataFrames([{'name': 'train', 'table': df_train}])
protostr = base64.b64encode(proto.SerializeToString()).decode("utf-8")

Lastly, you just copy and paste the code below. The code comes directly from GitHub. You should be able to see this:

# Display the facets overview visualization for this data# Displ
from IPython.core.display import display, HTML

HTML_TEMPLATE = """<link rel="import" href="/nbextensions/facets-dist/facets-jupyter.html" >
        <facets-overview id="elem"></facets-overview>
        <script>
          document.querySelector("#elem").protoInput = "{protostr}";
        </script>"""
html = HTML_TEMPLATE.format(protostr=protostr)
display(HTML(html))

Correlation Graph and Pair Grid

After you check the data and their distribution, you can plot a correlation matrix. The correlation matrix computes the Pearson coefficient. This coefficient is bounded between -1 and 1, where a positive value indicates a positive correlation and a negative value a negative correlation.

You are interested to see which variables can be a good candidate for interaction terms.

Version note: the mask below calls np.bool, an alias that was deprecated in NumPy 1.20 and removed in NumPy 1.24. On a recent NumPy the same line raises AttributeError: module 'numpy' has no attribute 'bool'; the builtin bool is the drop-in replacement.

## Choose important feature and further check with Dive
%matplotlib inline
import matplotlib.pyplot as plt
import seaborn as sns
sns.set(style="ticks")
# Compute the correlation matrix
corr = df.corr('pearson')
# Generate a mask for the upper triangle
mask = np.zeros_like(corr, dtype=np.bool)
mask[np.triu_indices_from(mask)] = True
# Set up the matplotlib figure
f, ax = plt.subplots(figsize=(11, 9))

# Generate a custom diverging colormap
cmap = sns.diverging_palette(220, 10, as_cmap=True)

# Draw the heatmap with the mask and correct aspect ratio
sns.heatmap(corr, mask=mask, cmap=cmap, vmax=.3, center=0,annot=True,
            square=True, linewidths=.5, cbar_kws={"shrink": .5})

Output

<matplotlib.axes._subplots.AxesSubplot at 0x1a184d6518>

In the heatmap above, darker squares mark stronger correlations. From the matrix, you can see:

• LSTAT
• RM

Are strongly correlated with PRICE. Another exciting feature is the strong positive correlation between NOX and INDUS, which means those two variables move in the same direction. Both are also correlated with PRICE. DIS is highly correlated with INDUS and NOX as well.

You have a first hint that INDUS and NOX can be good candidates for an interaction term and DIS might also be interesting to focus on.

You can go a little bit deeper by plotting a pair grid. It will illustrate more in detail the correlation map you plotted before.

The pair grid is composed as follows:

• Upper part: Scatter plot with fitted line
• Diagonal: Kernel density plot
• Lower part: Multivariate kernel density plot

You focus on four independent variables. The choice corresponds to the variables with strong correlation with PRICE

• INDUS
• NOX
• RM
• LSTAT

moreover, the PRICE.

Note that the standard error is added by default to the scatter plot.

attributes = ["PRICE", "INDUS", "NOX", "RM", "LSTAT"]

g = sns.PairGrid(df[attributes])
g = g.map_upper(sns.regplot, color="g")
g = g.map_lower(sns.kdeplot,cmap="Reds", shade=True, shade_lowest=False)
g = g.map_diag(sns.kdeplot)

Output

Let’s begin with the upper part:

• Price is negatively correlated with INDUS, NOX, and LSTAT; positively correlated with RM.
• There is a slight non-linearity between LSTAT and PRICE
• There is like a straight line when the price is equal to 50. From the description of the dataset, PRICE has been truncated at the value of 50

Diagonal: NOX seems to have two clusters, one around 0.5 and one around 0.85.

To check more about it, you can look at the lower part. The Multivariate Kernel Density is interesting in a sense it colors where most of the points are. The difference with the scatter plot draws a probability density, even though there is no point in the dataset for a given coordinate. When the color is stronger, it indicates a high concentration of point around this area.

If you check the multivariate density for INDUS and NOX, you can see the positive correlation and the two clusters. When the share of the industry is above 18, the nitric oxides concentration is above 0.6.

You can think about adding an interaction between INDUS and NOX in the linear relationship.

Finally, you can use the second tool created by Google, Facets Deep Dive. The interface is divided up into four main sections. The central area in the center is a zoomable display of the data. On the top of the panel, there is the drop-down menu where you can change the arrangement of the data to controls faceting, positioning, and color. On the right, there is a detailed view of a specific row of data. It means you can click on any dot of data in the center visualization to see the detail about that particular data point.

During the data visualization step, you are interested in looking for the pairwise correlation between the independent variable on the price of the house. However, it involves at least three variables, and 3D plots are complicated to work with.

One way to tackle this problem is to create a categorical variable. That is, we can create a 2D plot and colour the dots. You can split the variable PRICE into four categories, with each category being a quartile (i.e., 0.25, 0.5, 0.75). You call this new variable Q_PRICE.

## Check non linearity with important features
df['Q_PRICE'] =  pd.qcut(df['PRICE'], 4, labels=["Lowest", "Low", "Upper", "upper_plus"])
## Show non linearity between RM and LSTAT
ax = sns.lmplot(x="DIS", y="INDUS", hue="Q_PRICE", data=df, fit_reg = False,palette="Set3")

Using Facets Deep Dive

To open Deep Dive, you need to transform the data into a json format. Pandas has a method for that: call to_json on the DataFrame.

The first line of code sets the sprite size according to how many rows the dataset holds.

df['Q_PRICE'] =  pd.qcut(df['PRICE'], 4, labels=["Lowest", "Low", "Upper", "upper_plus"])
sprite_size = 32 if len(df.index)>50000 else 64
jsonstr = df.to_json(orient='records')

The code below comes from Google GitHub. After you run the code, you should be able to see this:

# Display thde Dive visualization for this data
from IPython.core.display import display, HTML

# Create Facets template
HTML_TEMPLATE = """<link rel="import" href="/nbextensions/facets-dist/facets-jupyter.html">
        <facets-dive sprite-image-width="{sprite_size}" sprite-image-height="{sprite_size}" id="elem" height="600"></facets-dive>
        <script>
          document.querySelector("#elem").data = {jsonstr};
        </script>"""

# Load the json dataset and the sprite_size into the template
html = HTML_TEMPLATE.format(jsonstr=jsonstr, sprite_size=sprite_size)

# Display the template
display(HTML(html))

You are interested to see if there is a connection between the industry rate, oxide concentration, distance to the job center and the price of the house.

For that, you first split the data by industry range and color with the price quartile:

• Select faceting X and choose INDUS.
• Select Display and choose DIS. It will color the dots with the quartile of the house price

Here, darker colours mean the distance to the first job centre is greater.

So far, it shows again what you know, lower industry rate, higher price. Now you can look at the breakdown by INDUX, by NOX.

Select faceting Y and choose NOX.

Now you can see the house far from the first job center have the lowest industry share and therefore the lowest oxide concentration. If you choose to display the type with Q_PRICE and zoom the lower-left corner, you can see what type of price it is.

You have another hint that the interaction between IND, NOX, and DIS can be good candidates to improve the model.

The exploration has produced two candidate interactions, so the next step is to test them in an actual model.

Linear Regression with TensorFlow

In this section, you will estimate the linear regression model with the TensorFlow Estimator API. You will proceed as follow:

• Prepare the data
• Estimate a benchmark model: No interaction
• Estimate a model with interaction

Version note: the tf-estimator package shipped its final release with TensorFlow 2.15 and is absent from TensorFlow 2.16 onwards, so tf.estimator.LinearRegressor runs only on TensorFlow 1.x unless you migrate it to a Keras linear model.

Remember, the goal of machine learning is to minimize the error. In this case, the model with the lowest mean squared error will win. The TensorFlow estimator automatically computes this metric.

Preparation data

In most cases, you need to transform your data. That is why Facets Overview is fascinating. From the summary statistic, you saw there are outliers. Those values affect the estimates because they do not look like the population you are analyzing. Outliers usually bias the results. For instance, a positive outlier tends to overestimate the coefficient.

A good solution to tackle this problem is to standardize the variable. Standardization means a standard deviation of one and a mean of zero. The process of standardization involves two steps. First of all, it subtracts the mean value of the variable. Secondly, it divides by the standard deviation so that the distribution has a unit standard deviation.

The library scikit-learn is helpful to standardize variables. You can use the module preprocessing with the object scale for this purpose.

You can use the function below to scale a dataset. Note that you don’t scale the label column and categorical variables.

from sklearn import preprocessing
def standardize_data(df):
    X_scaled = preprocessing.scale(df[['CRIM', 'ZN', 'INDUS', 'NOX', 'RM', 'AGE', 'DIS', 'RAD',
       'TAX', 'PTRATIO', 'B', 'LSTAT']])
    X_scaled_df = pd.DataFrame(X_scaled, columns = ['CRIM', 'ZN', 'INDUS', 'NOX', 'RM', 'AGE', 'DIS', 'RAD',
       'TAX', 'PTRATIO', 'B', 'LSTAT'])
    df_scale = pd.concat([X_scaled_df,
                       df['CHAS'],
                       df['PRICE']],axis=1, join='inner')
    return df_scale

You can use the function to construct the scaled train/test set.

df_train_scale = standardize_data(df_train)
df_test_scale = standardize_data(df_test)

Basic regression:Benchmark

First of all, you train and test a model without interaction. The purpose is to see the performance metric of the model.

The way to train the model is exactly as in the tutorial on the high-level API. You will use the TensorFlow estimator LinearRegressor.

As a reminder, you need to choose:

• the features to put in the model
• transform the features
• construct the linear regressor
• construct the input_fn function
• train the model
• test the model

You use all the variables in the dataset to train the model. In total, there are twelve continuous variables and one categorical variable

## Add features to the bucket:
### Define continuous list
CONTI_FEATURES  = ['CRIM', 'ZN', 'INDUS', 'NOX', 'RM', 'AGE', 'DIS', 'RAD','TAX', 'PTRATIO', 'B', 'LSTAT']
CATE_FEATURES = ['CHAS']

You convert the features into a numeric column or categorical column

continuous_features = [tf.feature_column.numeric_column(k) for k in CONTI_FEATURES]
#categorical_features = tf.feature_column.categorical_column_with_hash_bucket(CATE_FEATURES, hash_bucket_size=1000)
categorical_features = [tf.feature_column.categorical_column_with_vocabulary_list('CHAS', ['yes','no'])]

You create the model with the linearRegressor. You store the model in the folder train_Boston

model = tf.estimator.LinearRegressor(
	model_dir="train_Boston",
    feature_columns=categorical_features + continuous_features)

Output

INFO:tensorflow:Using default config.
INFO:tensorflow:Using config: {'_model_dir': 'train_Boston', '_tf_random_seed': None, '_save_summary_steps': 100, '_save_checkpoints_steps': None, '_save_checkpoints_secs': 600, '_session_config': None, '_keep_checkpoint_max': 5, '_keep_checkpoint_every_n_hours': 10000, '_log_step_count_steps': 100, '_train_distribute': None, '_service': None, '_cluster_spec': <tensorflow.python.training.server_lib.ClusterSpec object at 0x1a19e76ac8>, '_task_type': 'worker', '_task_id': 0, '_global_id_in_cluster': 0, '_master': '', '_evaluation_master': '', '_is_chief': True, '_num_ps_replicas': 0, '_num_worker_replicas': 1}

Each column in the train or test data is converted into a Tensor with the function get_input_fn

FEATURES = ['CRIM', 'ZN', 'INDUS', 'NOX', 'RM', 'AGE', 'DIS', 'RAD','TAX', 'PTRATIO', 'B', 'LSTAT', 'CHAS']
LABEL= 'PRICE'
def get_input_fn(data_set, num_epochs=None, n_batch = 128, shuffle=True):
    return tf.estimator.inputs.pandas_input_fn(
       x=pd.DataFrame({k: data_set[k].values for k in FEATURES}),
       y = pd.Series(data_set[LABEL].values),
       batch_size=n_batch,
       num_epochs=num_epochs,
       shuffle=shuffle)

You estimate the model on the train data.

model.train(input_fn=get_input_fn(df_train_scale,
                                      num_epochs=None,
                                      n_batch = 128,
                                      shuffle=False),
                                      steps=1000)

Output

INFO:tensorflow:Calling model_fn.
INFO:tensorflow:Done calling model_fn.
INFO:tensorflow:Create CheckpointSaverHook.
INFO:tensorflow:Graph was finalized.
INFO:tensorflow:Running local_init_op.
INFO:tensorflow:Done running local_init_op.
INFO:tensorflow:Saving checkpoints for 1 into train_Boston/model.ckpt.
INFO:tensorflow:loss = 56417.703, step = 1
INFO:tensorflow:global_step/sec: 144.457
INFO:tensorflow:loss = 76982.734, step = 101 (0.697 sec)
INFO:tensorflow:global_step/sec: 258.392
INFO:tensorflow:loss = 21246.334, step = 201 (0.383 sec)
INFO:tensorflow:global_step/sec: 227.998
INFO:tensorflow:loss = 30534.78, step = 301 (0.439 sec)
INFO:tensorflow:global_step/sec: 210.739
INFO:tensorflow:loss = 36794.5, step = 401 (0.477 sec)
INFO:tensorflow:global_step/sec: 234.237
INFO:tensorflow:loss = 8562.981, step = 501 (0.425 sec)
INFO:tensorflow:global_step/sec: 238.1
INFO:tensorflow:loss = 34465.08, step = 601 (0.420 sec)
INFO:tensorflow:global_step/sec: 237.934
INFO:tensorflow:loss = 12241.709, step = 701 (0.420 sec)
INFO:tensorflow:global_step/sec: 220.687
INFO:tensorflow:loss = 11019.228, step = 801 (0.453 sec)
INFO:tensorflow:global_step/sec: 232.702
INFO:tensorflow:loss = 24049.678, step = 901 (0.432 sec)
INFO:tensorflow:Saving checkpoints for 1000 into train_Boston/model.ckpt.
INFO:tensorflow:Loss for final step: 23228.568.


<tensorflow.python.estimator.canned.linear.LinearRegressor at 0x1a19e76320>

At last, you estimate the performances of the model on the test set

model.evaluate(input_fn=get_input_fn(df_test_scale,
                                      num_epochs=1,
                                      n_batch = 128,
                                      shuffle=False),
                                      steps=1000)

Output

INFO:tensorflow:Calling model_fn.
INFO:tensorflow:Done calling model_fn.
INFO:tensorflow:Starting evaluation at 2018-05-29-02:40:43
INFO:tensorflow:Graph was finalized.
INFO:tensorflow:Restoring parameters from train_Boston/model.ckpt-1000
INFO:tensorflow:Running local_init_op.
INFO:tensorflow:Done running local_init_op.
INFO:tensorflow:Finished evaluation at 2018-05-29-02:40:43
INFO:tensorflow:Saving dict for global step 1000: average_loss = 86.89361, global_step = 1000, loss = 1650.9785


{'average_loss': 86.89361, 'global_step': 1000, 'loss': 1650.9785}

The loss of the model is 1650.9785. This is the metric to beat in the next section

Improve the model: Interaction term

During the first part of the tutorial, you saw an interesting relationship between the variables. The different visualization techniques revealed that INDUS and NOX are linked together and magnify each other’s effect on the price. Not only does the interaction between INDUS and NOX affect the price but also this effect is stronger when it interacts with DIS.

It is time to generalize this idea and see whether you can improve the model prediction.

You need to add two new columns to each dataset: train and test. For that, you create one function to compute the interaction term and another one to compute the triple interaction term. Each function produces a single column. After the new variables are created, you can concatenate them to the training dataset and test dataset.

First of all, you need to create a new variable for the interaction between INDUS and NOX.

The function below returns two dataframes, train and test, with the interaction between var_1 and var_2, in your case INDUS and NOX.

def interaction_term(var_1, var_2, name):
    t_train = df_train_scale[var_1]*df_train_scale[var_2]
    train = t_train.rename(name)
    t_test = df_test_scale[var_1]*df_test_scale[var_2]
    test = t_test.rename(name)
    return train, test

You store the two new columns

interation_ind_ns_train, interation_ind_ns_test= interaction_term('INDUS', 'NOX', 'INDUS_NOS')
interation_ind_ns_train.shape
(325,)

Secondly, you create a second function to compute the triple interaction term.

def triple_interaction_term(var_1, var_2,var_3, name):
    t_train = df_train_scale[var_1]*df_train_scale[var_2]*df_train_scale[var_3]
    train = t_train.rename(name)
    t_test = df_test_scale[var_1]*df_test_scale[var_2]*df_test_scale[var_3]
    test = t_test.rename(name)
    return train, test
interation_ind_ns_dis_train, interation_ind_ns_dis_test= triple_interaction_term('INDUS', 'NOX', 'DIS','INDUS_NOS_DIS')

Now that you have all columns needed, you can add them to train and test dataset. You name these two new dataframe:

• df_train_new
• df_test_new

df_train_new = pd.concat([df_train_scale,
                          interation_ind_ns_train,
                          interation_ind_ns_dis_train],
                         axis=1, join='inner')
df_test_new = pd.concat([df_test_scale,
                         interation_ind_ns_test,
                         interation_ind_ns_dis_test],
                         axis=1, join='inner')
df_train_new.head(5)

Output

That is it: you can estimate the new model with the interaction terms and see how is the performance metric.

CONTI_FEATURES_NEW  = ['CRIM', 'ZN', 'INDUS', 'NOX', 'RM', 'AGE', 'DIS', 'RAD','TAX', 'PTRATIO', 'B', 'LSTAT',
                       'INDUS_NOS', 'INDUS_NOS_DIS']
### Define categorical list
continuous_features_new = [tf.feature_column.numeric_column(k) for k in CONTI_FEATURES_NEW]
model = tf.estimator.LinearRegressor(
    model_dir="train_Boston_1",
    feature_columns= categorical_features + continuous_features_new)

Output

INFO:tensorflow:Using default config.
INFO:tensorflow:Using config: {'_model_dir': 'train_Boston_1', '_tf_random_seed': None, '_save_summary_steps': 100, '_save_checkpoints_steps': None, '_save_checkpoints_secs': 600, '_session_config': None, '_keep_checkpoint_max': 5, '_keep_checkpoint_every_n_hours': 10000, '_log_step_count_steps': 100, '_train_distribute': None, '_service': None, '_cluster_spec': <tensorflow.python.training.server_lib.ClusterSpec object at 0x1a1a5d5860>, '_task_type': 'worker', '_task_id': 0, '_global_id_in_cluster': 0, '_master': '', '_evaluation_master': '', '_is_chief': True, '_num_ps_replicas': 0, '_num_worker_replicas': 1}

Code

FEATURES = ['CRIM', 'ZN', 'INDUS', 'NOX', 'RM', 'AGE', 'DIS', 'RAD','TAX', 'PTRATIO', 'B', 'LSTAT','INDUS_NOS', 'INDUS_NOS_DIS','CHAS']
LABEL= 'PRICE'
def get_input_fn(data_set, num_epochs=None, n_batch = 128, shuffle=True):
    return tf.estimator.inputs.pandas_input_fn(
       x=pd.DataFrame({k: data_set[k].values for k in FEATURES}),
       y = pd.Series(data_set[LABEL].values),
       batch_size=n_batch,
       num_epochs=num_epochs,
       shuffle=shuffle)

model.train(input_fn=get_input_fn(df_train_new,
                                      num_epochs=None,
                                      n_batch = 128,
                                      shuffle=False),
                                      steps=1000)

Output

INFO:tensorflow:Calling model_fn.
INFO:tensorflow:Done calling model_fn.
INFO:tensorflow:Create CheckpointSaverHook.
INFO:tensorflow:Graph was finalized.
INFO:tensorflow:Running local_init_op.
INFO:tensorflow:Done running local_init_op.
INFO:tensorflow:Saving checkpoints for 1 into train_Boston_1/model.ckpt.
INFO:tensorflow:loss = 56417.703, step = 1
INFO:tensorflow:global_step/sec: 124.844
INFO:tensorflow:loss = 65522.3, step = 101 (0.803 sec)
INFO:tensorflow:global_step/sec: 182.704
INFO:tensorflow:loss = 15384.148, step = 201 (0.549 sec)
INFO:tensorflow:global_step/sec: 208.189
INFO:tensorflow:loss = 22020.305, step = 301 (0.482 sec)
INFO:tensorflow:global_step/sec: 213.855
INFO:tensorflow:loss = 28208.812, step = 401 (0.468 sec)
INFO:tensorflow:global_step/sec: 209.758
INFO:tensorflow:loss = 7606.877, step = 501 (0.473 sec)
INFO:tensorflow:global_step/sec: 196.618
INFO:tensorflow:loss = 26679.76, step = 601 (0.514 sec)
INFO:tensorflow:global_step/sec: 196.472
INFO:tensorflow:loss = 11377.163, step = 701 (0.504 sec)
INFO:tensorflow:global_step/sec: 172.82
INFO:tensorflow:loss = 8592.07, step = 801 (0.578 sec)
INFO:tensorflow:global_step/sec: 168.916
INFO:tensorflow:loss = 19878.56, step = 901 (0.592 sec)
INFO:tensorflow:Saving checkpoints for 1000 into train_Boston_1/model.ckpt.
INFO:tensorflow:Loss for final step: 19598.387.


<tensorflow.python.estimator.canned.linear.LinearRegressor at 0x1a1a5d5e10>

model.evaluate(input_fn=get_input_fn(df_test_new,
                                      num_epochs=1,
                                      n_batch = 128,
                                      shuffle=False),
                                      steps=1000)

Output

INFO:tensorflow:Calling model_fn.
INFO:tensorflow:Done calling model_fn.
INFO:tensorflow:Starting evaluation at 2018-05-29-02:41:14
INFO:tensorflow:Graph was finalized.
INFO:tensorflow:Restoring parameters from train_Boston_1/model.ckpt-1000
INFO:tensorflow:Running local_init_op.
INFO:tensorflow:Done running local_init_op.
INFO:tensorflow:Finished evaluation at 2018-05-29-02:41:14
INFO:tensorflow:Saving dict for global step 1000: average_loss = 79.78876, global_step = 1000, loss = 1515.9863


{'average_loss': 79.78876, 'global_step': 1000, 'loss': 1515.9863}

The new loss is 1515.9863. Just by adding two new variables, you were able to decrease the loss. It means you can make a better prediction than with the benchmark model.

Both figures come from the same 101-row test split, so the drop of roughly 8 percent in average loss is attributable to the two interaction columns alone.

FAQs
