Robotium Tutorial: Android Testing Framework with Example

What is Robotium?

Robotium is an Android testing framework that automates test cases for native and hybrid applications. Using Robotium, a developer can create robust automated GUI test cases for Android applications. A developer can also write functional, system and acceptance test scenarios that span several Android activities.

Robotium Testing Framework

The standard Android testing framework carries the limitations listed below.

• Unable to handle multiple activities
• Test execution performance is slow
• Test cases are complex and hard to implement

The Robotium framework is the better choice for conducting testing on an Android application.

Robotium is an open-source framework and is considered an extension of the Android test framework. Using Robotium, a developer can create robust automated GUI test cases for Android applications. Moreover, a developer can write functional, system and acceptance test scenarios that span multiple Android activities.

The table below summarises the advanced features that separate Robotium from the plain instrumentation framework.

Advanced features of Robotium

Robotium Test Case Classes

Robotium ships a small set of classes for testing, and the article's example imports the legacy com.jayway.android.robotium.solo package. These classes support test cases that span multiple activities, and Solo is integrated with ActivityInstrumentationTestCase2.

Note: current Robotium releases expose the same class under the shorter com.robotium.solo package, while the Maven coordinate stayed com.jayway.android.robotium:robotium-solo. Adjust the import to match the JAR version you actually add to the project.

The diagram below shows how the Solo class sits on top of the instrumentation test case.

Integration of Robotium and ActivityInstrumentationTestCase2

A tester can write test cases without knowledge of the application design, which makes the approach a form of black box testing. That is an outstanding advantage compared with the plain Android test case classes.

How to Use Robotium

To use Robotium in your Android test project, you need to follow the steps below.

How to use Robotium

To guarantee the quality of your Android application, follow the four-stage procedure below.

• Design the test specification
• Develop the test program
• Execute the test case on the target device
• Collect the test result

The flow chart below places those four stages in order.

Android application testing procedure

STEP 1) Design Test Specification

This is the first step in testing your application. In this step you define the target to be tested. An Android application has many targets that need to be tested, such as the UI, activities, components and services. Clearly defining the target helps you achieve wide test coverage.

• Plan the test types that should be conducted (unit test, functional test, system test).
• Design each test case for maximum coverage while keeping the number of test cases small. The more code you test, the higher the chance of early bug detection.

STEP 2) Write Test Program

This section guides you through writing an Android test program using Android JUnit tests and Robotium. Assume you have already developed an Android program named HelloAndroid. This program has the functions described below.

• Display the text “Hello world!” on screen.
• Display a HelloAndroid message when the user presses the “Start” button.

The screenshot below shows the application under test running on a device.

HelloAndroid application

System Requirements

• The Android platform ships with a pre-integrated JUnit 3 framework, which is what ActivityInstrumentationTestCase2 builds on.
• To create an Android test project from Eclipse, your machine needs a working Android SDK installation.
• Install the current Android platform SDK rather than a pinned older release.

The screenshots in this walkthrough use Eclipse with the ADT plugin, which was the standard toolchain when the example was written. Eclipse ADT is no longer supported, so on a modern machine you would download Android Studio instead and reuse the same test code inside a Gradle module.

For the Robotium testing framework, download the Robotium library from the Robotium project page.

Create an Android Test Project

• Click File -> New -> Other
• Choose Android -> Android Test Project as shown in the figure below, then choose Next

Create a new Android test project

Write the name of your test project. By naming convention, the test project should be named “HelloAndroidTest”.

Add the test project name based on the naming convention

Choose the target application under test. In this case it is HelloAndroid, then click Finish.

Choose the target application under test

Create Test Suites

Based on your test specification, you now create test suites for your test program. You can choose from various software testing frameworks. This tutorial uses the standard Android testing framework ActivityInstrumentationTestCase2. To test with Robotium, add the Robotium library file to a libs directory inside your project folder.

A test case defines the fixture used to run multiple tests. To define a test case, follow the program structure below.

• Implement a subclass of TestCase.
• Define instance variables that store the state of the fixture.
• Initialize the fixture state by overriding setUp().
• Clean up after a test by overriding tearDown().

The diagram below maps that structure onto the test program you are about to write.

Test program structure

package com.example.helloandroid.test;

import com.example.helloandroid.HelloAndroid;
import com.jayway.android.robotium.solo.Solo;
import android.test.ActivityInstrumentationTestCase2;
import android.widget.TextView;

public class HelloAndroidTest extends ActivityInstrumentationTestCase2 <HelloAndroid> {

	private HelloAndroid mActivity;
	private TextView mView;
	private String resourceString;
	private Solo solo;

	public HelloAndroidTest () {
		// TODO Auto-generated constructor stub
		super("com.example.helloandroid",HelloAndroid.class);
	}

	 @Override
	protected void setUp() throws Exception {
		// TODO Auto-generated method stub
	//	super.setUp();

	 	mActivity = this.getActivity();
		solo = new Solo(getInstrumentation(),getActivity());
		mView = (TextView) mActivity.findViewById(com.example.helloandroid.R.id.textview2);
		resourceString = mActivity.getString(com.example.helloandroid.R.string.hello_world);

	}

	 @Override
	protected void tearDown() throws Exception {
		// TODO Auto-generated method stub
		//super.tearDown();
		solo.finishOpenedActivities();
	}

	public void testPrecondition() {
		assertNotNull(mView);
	}

	/* test Target application contains a text display "Hello World!"*/
	public void testSearchText() {
		assertEquals(resourceString,(String) mView.getText());
	}

	/* test HelloAndroid Activity on target application is exist*/
	public void testCurrentActivity() throws Exception  {
    	solo.assertCurrentActivity("wrong activity", HelloAndroid.class);
    }

	/* test Application UI contains "Start" button */
	/* send event click button to target application */
    public void testSearchButton() throws Exception {
    	boolean found = solo.searchButton("Start");
    	solo.clickOnButton("Start");
    	assertTrue(found);
    }



}

Adding Test Cases

• In the same package as the test suite, create the TestCase classes.
• To test a certain activity, for example HelloAndroid, create a test case extending ActivityInstrumentationTestCase2<HelloAndroid>.
• Inside that class, the tester obtains the activity under test through the getActivity() method.
• Create a test for the activity freely by adding a method named “test + original method name”.
• Inside the test method, the tester can use Android JUnit functions to compare the actual value with the expected value. These methods are shown below.

The table below lists the assertion and interaction methods most often used in the two frameworks.

Example methods of Robotium and the Android testing framework

The test suite above verifies that the application GUI displays the text “Hello World!” and contains a button named “Start”.

STEP 3) Run Test

After you finish writing your test program, run the test using the steps below.

• Connect an Android device to your PC, or start an emulator if no real device is available.
• In your IDE, right-click the test project and choose Run As → Android Unit Test.

The screenshot below shows the test run being launched from the IDE.

Running the test program

Besides running the test from the IDE, you can run it from the command line. In this test program the test package is com.example.helloandroid.test. In a Linux terminal, use the following command to run every test in that package.

$ adb shell am instrument -w -e package com.example.helloandroid.test

STEP 4) Get Test Result

After the test executes, you collect the test results.

In this test program four test methods are executed. In the run below, all test cases passed.

Test result output when all test cases pass

If a test case fails, the output is displayed and shows you which test cases failed.

Test result output when a test case fails

Source Code Examples

This article includes source code examples that help you follow the tutorial more clearly and pick up the technical detail quickly.

• HelloAndroid: the application under test.
• HelloAndroidTest: the test program using the Android test framework.
