CodeIgniter Form Validation with Form Submit Example

Form in CodeIgniter

Forms provide a way for users to interact with the application and submit data. It can be used for a contact us form that a visitor to the website can fill in and send the information to us. The information received is usually stored in the database or send via email.

HTML Form Structure

The following code shows the structure of a typical HTML form.

<form id="frmUsers" name="frmUsers" method="POST" action="create_user.php">
	<input type="text" id="user_id" name="user_id">
	<input type="password" id="password" name="password">

	<input type="submit" value="Submit">
</form>

HERE,

  • <form>…</form> are the opening and closing tags of the form. The id and name attribute specify the name and id of the form. The method attribute specifies the HTTP Verb to be used. This is usually specified by POST verb
  • <input…> Specifies the form elements. The name attribute is the variable name that is submitted to the backend server for processing.

CodeIgniter Form Helper

HTML is great is easy to understand and write, but CodeIgniter makes things even simpler. CodeIgniter has built-in functions to create HTML forms.

Let’s consider the following CodeIgniter form submit code that uses the form helper to create a form

 <?php
        echo form_open('create_user.php', ['id' => 'frmUsers']);

        echo form_label('User Id', 'user_id');
        echo form_input(['name' => 'user_id']);

        echo form_label('Password', 'password');
        echo form_input(['type' => 'password', 'name' => 'password']);

        echo form_submit('btnSubmit', 'Create User');

        echo form_close();
        ?>

HERE,

  • echo form_open(‘create_user.php’, [‘id’ => ‘frmUsers’]); creates the form’s opening tag, sets the action to POST Verb and sets the action URL to create_user.php
  • echo form_label(‘User Id’, ‘user_id’); creates a label that reads User Id for the input field with the name of user_id.
  • echo form_input([‘name’ => ‘user_id’]); creates an input field of text type with the name of user_id
  • echo form_submit(‘btnSubmit’, ‘Create User’); creates a submit button with the label of Create User
  • echo form_close(); closes the form

As you can see from the above CodeIgniter code, form helpers make it easy for us to create forms using pure PHP. By passing attributes to the form helper methods, we can customize the HTML that is generated for the form.

The above code generates the following HTML form code

        <form action="http://localhost:3000/index.php/create_user.php" id="frmUsers" method="post" accept-charset="utf-8">
            <label for="user_id">User Id</label>
            <input type="text" name="user_id" value=""/>

            <label for="password">Password</label>
            <input type="password" name="password" value=""/>

            <input type="submit" name="btnSubmit" value="Create User"/>
        </form>

The biggest advantages of using the form helper is that it generates semantically correct code that adheres to the set HTML standards.

You can refer to the official CodeIgniter documentation for more details

https://codeigniter.com/user_guide/helpers/form_helper.html

CodeIgniter Form Example

After covering the basics of CodeIgniter, let’s get back to our tutorial project which we have been working on throughout this CodeIgniter Tutorial Series. In summary, the tutorial project builds a contacts management app that will store the details in the database.

Create Contact

in the previous tutorial, we created routes for our applications and simple views. Open application/views/contacts/create.php

Modify the code for create.php as follows

<div class="column">
    <h2 class="title">Create Contact</h2>
    <form action="<?= base_url('contacts/store') ?>" method="POST">
        <div class="field">
            <label class="label">Contact Name</label>
            <div class="control">
                <input id="name" name="name" class="input" type="text" placeholder="Type the contact name">
            </div>
        </div>
        <div class="field">
            <label class="label">Contact Number</label>
            <div class="control">
                <input id="name" name="name" class="input" type="text" placeholder="Type the contact number">
            </div>
        </div>
        <div class="field">
            <label class="label">Email Address</label>
            <div class="control">
                <input id="email" name="email" class="input" type="email" placeholder="Type the email address">
            </div>
        </div>
        <div class="field is-grouped">
            <div class="control">
                <button class="button is-link">Save Contact</button>
            </div>
        </div>
    </form>
</div>

Note: the above code uses plain HTML to create forms.

Let’s now see how our forms look like in the web browser

Load the following URL into our web browser.

http://localhost:3000/contacts/create

If you have been creating the tutorial project, then you should be able to see the following

CodeIgniter Form

Form Validation in CodeIgniter

Validation plays a very critical role when processing data from forms. Let’s say a user is signing up on a website; we want to make sure that they fill in their required details and email address. We need to make sure that the email address that has been entered is valid. If we are working with date values, then we want to make sure the date ranges are valid. We wouldn’t have to accept a date that has 32 days in a month etc.

Validation solves the above problems. CodeIgniter Validation is done on two (2) fronts when working with web applications.

Client-side validation is done on the part of the web browser. This usually involves the use of HTML and JavaScript. Client-side validation improves performance as everything is done at the client-side. So, there is no need to submit the data to the server. The disadvantage of client-side validation is the user has control over it. If you rely on JavaScript to validate and the user disables JavaScript in the browser, then your validation will fail.

Server-side validation is done on the server-side. The downside of this validation is the user has to submit the data to the server for processing and wait for the response. This uses up network resources and may degrade the performance. The major advantage of server-side validation is you have greater control and you are assured of your validation rules working even if the user disables JavaScript in the browser.

A better strategy is to use client-side as the primary validation strategy and server-side as a fallback mechanism.

Adding Form Validation Rules

CodeIgniter has a built-in validation library. The library is loaded using the following line

$this->load->library('form_validation');

The CodeIgniter form validation library can be used to perform some of the following actions

  • Check for required fields. This examines the submitted values and returns an error if a field that has been tagged as required does not have a value
  • Data type validation – some fields may require numeric values only. If a non-numeric value is detected, then the library returns an error. Execution of the form submission is also aborted.
  • Length validation – some data types require fields to have a certain minimum or a maximum number of characters. The validation library comes in handy in such cases.
  • Data sanitization – the validation library also has capabilities that remove malicious code from the submitted data for security reasons. If for example, the submitted values have active JavaScript or SQL Injection code in them, the validation library strips away the harmful code and renders it useless.
  • Validate unique database fields – suppose you have a form where users sign up using an email address. You would want to ensure that the email address is unique. The library makes it easy for you to check the submitted data against a database table and field. This allows you to know that the value has already been taken up.

Validation rules are set using the following format

$this->form_validation->set_rules('field','human readable field','rule',['custom message']);

HERE,

  • ‘field’ specified the form field name to be validated by the library
  • ‘human readable field’ specifies the human-readable format of the field under validation. This is displayed back to the user when an error occurs.
  • ‘rule’ specifies the validation rule to be applied such as required, numeric, check if minimum length is… etc.
  • [‘custom message’] is optional and can be used to set a custom validation message that should be displayed when the validation rule fails.

Following is a form submit in CodeIgniter example for validating the contact name

$this->form_validation->set_rules('contact_number', 'Contact Number', 'required');

HERE,

  • The above code checks if the field contact_number has been entered. If it is not set then returns an error that says Contact Number field is required.

To run the validation against the set rules, we use the following function of the validation library

$this->form_validation->run()

If the above code returns false, then one or more set rules have failed. If it returns true, then the validation rules have all passed, and you may proceed with further action.

Let’s look at more examples of validation rules. Suppose you want to validation some fields say the contact name, number and email address, you can use the following code to accomplish that.

$rules = array(
        array(
                'field' => 'contact_name',
                'label' => 'Contact Name',
                'rules' => 'required'
        ),
        array(
                'field' => 'contact_number',
                'label' => 'Contact Number',
                'rules' => 'required',
                'errors' => array(
                        'required' => 'You must provide a %s.',
                ),
        ),
        array(
                'field' => 'email_address',
                'label' => 'Email Address',
                'rules' => 'required'
        )
);

$this->form_validation->set_rules($rules);

HERE,

  • In the above email validation in CodeIgniter example, we provide an array of fields with rules for the set_rules function of the library. This makes it easier when you are validating some fields.

Unique Validation

If we want to validate the contact number to ensure that we do not save the same number twice, we can use the following rule to do that.

$this->form_validation->set_rules('contact_number', 'Contact Number','required|is_unique[contacts.contact_number]');

HERE,

  • | is used to pipe multiple rules together
  • is_unique[contacts.contact_number] checks if the value for contact_number is unique against the contact_number field values in the database table contacts.

Displaying Form Validation Error Messages

If an error occurs during the processing of the form, you can use the following code to display the validation errors that occurred

<?php echo validation_errors(); ?>

HERE,

  • The above function returns all the errors that occurred.

Populating Submitted Form Data: Sticky Forms

Some forms have many fields, and if an error has occurred, then you want to make sure that the data that was added correctly is preserved. The validation library has mechanisms for accomplishing that. We do that by using the following code.

<?php echo set_value('field_name'); ?>

HERE,

  • The above code displays that input that the user had entered.

For a complete reference guide on the methods that are available under the validation library, you can refer to the API documentation from the official user guide for CodeIgniter

https://codeigniter.com/userguide3/libraries/form_validation.html

CodeIgniter Form Validation Example

Throughout these tutorial series, we have been adding more code to our tutorial project which is a contacts management application. In this section, we will load the validation library and see how we can put it to practical use using a real-world example application.

Modify the routes code as follows to include the store method

$route['default_controller'] = 'welcome';
$route['contacts'] = 'contacts';
$route['create'] = 'contacts/create';
$route['store'] = 'contacts/store';
$route['edit/:id'] = 'contacts/edit';
$route['update/:id'] = 'contacts/update';
$route['delete/:id'] = 'contacts/delete';
$routes['users'] = 'welcome/users';

Let’s now load the form validation library in the Contacts controller and set some validation rules.

Modify the code as shown in the below form validation in CodeIgniter example:

<?php

defined('BASEPATH') OR exit('No direct script access allowed');

class Contacts extends CI_Controller {

    public function __construct() {
        parent::__construct();
        $this->load->helper('url', 'form');
        $this->load->library('form_validation');
    }

    public function index() {
        $this->load->view('header');
        $this->load->view('contacts/index');
        $this->load->view('footer');
    }

    public function create() {
        $this->load->view('header');
        $this->load->view('contacts/create');
        $this->load->view('footer');
    }

    public function store() {
        $rules = array(
            array(
                'field' => 'contact_name',
                'label' => 'Contact Name',
                'rules' => 'required'
            ),
            array(
                'field' => 'contact_number',
                'label' => 'Contact Number',
                'rules' => 'required',
                'errors' => array(
                    'required' => 'You must provide a %s.',
                ),
            ),
            array(
                'field' => 'email_address',
                'label' => 'Email Address',
                'rules' => 'required'
            )
        );

        $this->form_validation->set_rules($rules);

        if ($this->form_validation->run() == FALSE) {
            $this->load->view('header');
            $this->load->view('contacts/create');
            $this->load->view('footer');
        } else {
            redirect(base_url('contacts'));
        }
    }

    public function edit($id) {
        $this->load->view('header');
        $this->load->view('contacts/edit');
        $this->load->view('footer');
    }

    public function update($id) {
        $this->load->view('header');
        $this->load->view('contacts/update');
        $this->load->view('footer');
    }

    public function delete($id) {
        $this->load->view('header');
        $this->load->view('contacts/delete');
        $this->load->view('footer');
    }
}

HERE,

  • $rules = array(…) sets defines the validation rules
  • $this->form_validation->set_rules($rules); sets the validation rules
  • if ($this->form_validation->run() == FALSE) {…} runs the validation rules and if they fail the form is redisplayed with validation errors. If the validation passes, we are simply redirecting to the list contacts page. Under normal circumstances we would write the data to the database. We will do that in the next tutorials when we look at databases.

Modify the create view in application/contacts/create.php code as shown in the below form validation CodeIgniter example:

<div class="column">
    <h2 class="title">Create Contact</h2>
    <div class="notification is-danger">
    <?php echo validation_errors(); ?>
    </div>
    <form action="<?= base_url('contacts/store') ?>" method="POST">
        <div class="field">
            <label class="label">Contact Name</label>
            <div class="control">
                <input id="contact_name" name="contact_name" class="input" type="text" value="<?php echo set_value('contact_name'); ?>" placeholder="Type the contact name">
            </div>
        </div>
        <div class="field">
            <label class="label">Contact Number</label>
            <div class="control">
                <input id="contact_number" name="contact_number" class="input" type="text" value="<?php echo set_value('contact_number'); ?>" placeholder="Type the contact number">
            </div>
        </div>
        <div class="field">
            <label class="label">Email Address</label>
            <div class="control">
                <input id="email_address" name="email_address" class="input" type="email" value="<?php echo set_value('email_address'); ?>" placeholder="Type the email address">
            </div>
        </div>
        <div class="field is-grouped">
            <div class="control">
                <button class="button is-link">Save Contact</button>
            </div>
        </div>
    </form>
</div>

HERE,

  • <?php echo validation_errors(); ?> we display the errors that occur if any during the validation process
  • <?php echo set_value(‘contact_name’); ?> sets the value that was previously set if any

You need to load the following URL into your web browser. Then click on Create Contact without entering any values

CodeIgniter Form Validation

Summary

  • Forms provide a way for users to interact with the application and submit data.
  • HTML is great is easy to understand and write, but CodeIgniter makes things even simpler. CodeIgniter has built-in functions to create HTML forms.
  • Validation plays a very critical role when processing data from forms.
  • In this tutorial, we have seen major validation strategies and their pros and cons. We also learned how- to set validation rules and out error messages using CodeIgniter’s built-in validation library. We have ended the lesson by implementing the knowledge gained in a practical application.
