What is Debugging in JSP?

Debugging in JSP is the process to trace the error in the application. It is not very easy to trace bugs and error in the application. JSP applications are client interactive. Hence, errors are difficult to reproduce.

In this tutorial, you will learn:

JSP Debugging Techniques

There are 3 different techniques through which we can debug a JSP application:

  • Using println statements
  • Using Java Logger
  • Using Debugger tools

Using println Statements

  • System.out.println() is used to trace whether certain part is executed or not.
  • We can print the variables in the code.
  • Also, we can print values which need to be used to debug the application.

Example:

In this example, we are debugging through the println statements to understand what values we are getting for the variables.

<%@ page language="java" contentType="text/html; charset=ISO-8859-1"
    pageEncoding="ISO-8859-1"%>
<!DOCTYPE html PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN" "http://www.w3.org/TR/html4/loose.dtd">
<html>
<head>
<meta http-equiv="Content-Type" content="text/html; charset=ISO-8859-1">
<title>Debug Guru JSP</title>
</head>
<body>
<% int num1=10;
System.out.println("This is debugging Guru JSP");
num1++;
int num2=num1/0;
System.out.println(num2);%>
</body>
</html>

Explanation of the code:

Code Line 10: We are taking variable num1 and initializing it to 10.

Code Line 11: We are printing using println statements that “This is debugging Guru JSP” to debug which line of code has been executed

Code Line 12: Here we are incrementing the variable num1 with 1.

Code Line 13: we are dividing the num1 by 0 and putting into a new variable num2.

Code Line 14: As we want to know the value for num2 we can fetch using the println statement to know till which line of code has been executed.

When you execute the above code, you get the following output:

JSP Debugging Using println Statements

Output:

Here, we are getting the statement “This is debugging Guru JSP” with the value of the variable num1 which has been incremented hence 11.

Using Java Logger

  • The Java logging framework is used for logging services for any class running in JVM.
  • This is used to log any information from the code.
  • It logs all necessary information to trace the bugs which have occurred.

Example:

In this example, we are using java logger to trace the information in the code.

Messages can be shown using different functions like severe(), warning(), info(), config(). Fine()

Info is used to show the information in the log file .

Severe is used to show some severe information on the log file.

<%@taglib prefix="guru" uri="http://java.sun.com/jsp/jstl/core" %>
<%@page import="java.util.logging.Logger" %>
<%@page import="java.util.Date" %>
<%@ page language="java" contentType="text/html; charset=ISO-8859-1"
    pageEncoding="ISO-8859-1"%>
<!DOCTYPE html PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN" "http://www.w3.org/TR/html4/loose.dtd">
<html>
<head>
<meta http-equiv="Content-Type" content="text/html; charset=ISO-8859-1">
<title>Debugging Guru JSP</title>
</head>
<body>
<% Logger logger=Logger.getLogger(this.getClass().getName());%>
<% Date dt = new Date();
logger.info(dt.toString());
logger.info("This is Guru Logging debugger"); %>
</body>
</html>

Explanation of the code:

Code Line 2: We are importing the java logger to log the information.

Code Line 3: We are importing Date class of the util package

Code Line 13: We are initializing the logger class by using getLogger method.

Code Line 14: We are initializing the date class.

Code Line 15: we are using the info method of logger class object to print the current date.

Code Line 16: We are using the info method to print ‘This is Guru Logging debugger’.

When you execute the above code, you will get the following output

JSP Debugging Using Java Logger

Output:

We will get the output in std.log, which will store in Logging folder in the server. Here we will get the information which has been written in the code.

Using Debugging Tools

We have been using eclipse since the beginning of the tutorial. In eclipse, we have debugging tools to debug the errors or bugs in the code.

How To Debug JSP in Eclipse

Here are the steps to debug a JSP application in Eclipse using debugging tools:

  1. Set the Breakpoint
  2. Restart Server in Debugging Mode
  3. Debug through Breakpoints

Step 1) Set the Breakpoint

We can set the breakpoint in the code, where we want to trace the code:

<%@ page language="java" contentType="text/html; charset=ISO-8859-1"
    pageEncoding="ISO-8859-1"%>
<!DOCTYPE html PUBLIC "-//W3C//DTD HTML 4.01 Transitional//EN" "http://www.w3.org/TR/html4/loose.dtd">
<html>
<head>
<meta http-equiv="Content-Type" content="text/html; charset=ISO-8859-1">
<title>Debugging Guru JSP</title>
</head>
<body>
<% String name = "This is test Guru JSP";
out.println(name);
%>
</body>
</html>

Here we are setting the breakpoint as ‘toggle breakpoint’ when you right click on the project explorer. We can set the breakpoints where the error or bug is occurring.

Once they are set, the debugger will move to the first breakpoint and then next and so on. It will run through the application with the help of breakpoints.

After setting the breakpoint, we need to restart the server in debug mode.

Step 2) Restart Server in Debugging Mode

We can restart the server in debugging by clicking on the server side and click on start in debug mode.

JSP Debugging Using Debugging Tools

Step 3) Debug through Breakpoints

We can debug the application by clicking on the application as debug as:

JSP Debugging Using Debugging Tools

You get an alert to switch the perspective then click “Yes” button.

After clicking ‘yes’ button we will get the following perspective:

Debugging in JSP Using Debugging Tools

We will get the variables tab, where we can see values of the variables:

Debugging in JSP Using Debugging Tools

The breakpoints tab shows number of breakpoints in the code:

Debugging in JSP Using Debugging Tools

We can debug the application through the breakpoints which have been set.

Summary

  • Debugging in JSP is the process to trace the error in the application.
  • JSP Debugging Techniques: Using println statements, Using Java Logger, and Using Debugger tools
  • System.out.println() is used to trace whether certain part is executed or not.
  • The Java logging framework is used for logging services for any class running in JVM.
  • In eclipse, we have debugging tools to debug the errors or bugs in the code.
