What is Hive Query Language: HiveQL Operators

What is Hive Query Language (HiveQL)?

Hive Query Language (HiveQL) is a query language in Apache Hive for processing and analyzing structured data. It separates users from the complexity of Map Reduce programming. It reuses common concepts from relational databases, such as tables, rows, columns, and schema, to ease learning. Hive provides a CLI for Hive query writing using Hive Query Language (HiveQL).

Most interactions tend to take place over a command line interface (CLI). Generally, HiveQL syntax is similar to the SQL syntax that most data analysts are familiar with. Hive supports four file formats which are: TEXTFILE, SEQUENCEFILE, ORC and RCFILE (Record Columnar File).

Hive uses derby database for single user metadata storage, and for multiple user Metadata or shared Metadata case, Hive uses MYSQL.

HiveQL Built-in Operators

Hive provides Built-in operators for Data operations to be implemented on the tables present inside Hive warehouse.

These operators are used for mathematical operations on operands, and it will return specific value as per the logic applied.

Below are the main types of Built-in Operators in HiveQL:

  • Relational Operators
  • Arithmetic Operators
  • Logical Operators
  • Operators on Complex types
  • Complex type Constructors

Relational Operators in Hive SQL

We use Relational operators for relationship comparisons between two operands.

  • Operators such as equals, Not equals, less than, greater than …etc
  • The operand types are all number types in these Operators.

The following Table will give us details about Relational operators and its usage in HiveQL:

Built-in Operator Description Operand
X = Y TRUE

if expression X is equivalent to expression Y

Otherwise FALSE.

It takes all primitive types
X != Y TRUE

if expression X is not equivalent to expression Y

Otherwise FALSE.

It takes all primitive types
X < Y TRUE

if expression X is less than expression Y

Otherwise FALSE.

It takes all primitive types
X <= Y TRUE

if expression X is less than or equal to expression Y

Otherwise FALSE.

It takes all primitive types
X>Y TRUE

if expression X is greater than expression Y

Otherwise FALSE.

It takes all primitive types
X>= Y TRUE

if expression X is greater than or equal to expression Y

Otherwise FALSE.

It takes all primitive types
X IS NULL TRUE if expression X evaluates to NULL otherwise FALSE. It takes all types
X IS NOT NULL FALSE

If expression X evaluates to NULL otherwise TRUE.

It takes all types
X LIKE Y TRUE

If string pattern X matches to Y otherwise FALSE.

Takes only Strings
X RLIKE Y NULL if X or Y is NULL, TRUE if any substring of X matches the Java regular expression Y, otherwise FALSE. Takes only Strings
X REGEXP Y Same as RLIKE. Takes only Strings

HiveQL Arithmetic Operators

We use Arithmetic operators for performing arithmetic operations on operands

  • Arithmetic operations such as addition, subtraction, multiplication and division between operands we use these Operators.
  • The operand types all are number types in these Operators

Sample Example:

2 + 3 gives result 5.

In this example, ‘+’ is theoperator and 2 and 3 are operands. The return value is 5

The following Table will give us details about Arithmetic operators in Hive Query Language:

Built-in Operator Description Operand
X + Y It will return the output of adding X and Y value. It takes all number types
X – Y It will return the output of subtracting Y from X value. It takes all number types
X * Y It will return the output of multiplying X and Y values. It takes all number types
X / Y It will return the output of dividing Y from X. It takes all number types
X % Y It will return the remainder resulting from dividing X by Y. It takes all number types
X & Y It will return the output of bitwise AND of X and Y. It takes all number types
X | Y It will return the output of bitwise OR of X and Y. It takes all number types
X ^ Y It will return the output of bitwise XOR of X and Y. It takes all number types
~X It will return the output of bitwise NOT of X. It takes all number types

Hive QL Logical Operators

We use Logical operators for performing Logical operations on operands

  • Logical operations such as AND, OR, NOT between operands we use these Operators.
  • The operand types all are BOOLEAN type in these Operators

The following Table will give us details about Logical operators in HiveSQL:

Operators Description Operands
X AND Y TRUE if both X and Y are TRUE, otherwise FALSE. Boolean types only
X && Y Same as X AND Y but here we using && symbol Boolean types only
X OR Y TRUE if either X or Y or both are TRUE, otherwise FALSE. Boolean types only
X || Y Same as X OR Y but here we using || symbol Boolean types only
NOT X TRUE if X is FALSE, otherwise FALSE. Boolean types only
!X Same as NOT X but here we using! symbol Boolean types only

Operators on Complex Types

The following Table will give us details about Complex Type Operators . These are operators which will provide a different mechanism to access elements in complex types.

Operators Operands Description
A[n] A is an Array and n is an integer type It will return nth element in the array A. The first element has index of 0
M[key] M is a Map<K, V> and key has type K It will return the values belongs to the key in the map

Complex Type Constructors

The following Table will give us details about Complex type Constructors. It will construct instances on complex data types. These are of complex data types such as Array, Map and Struct types in Hive.

In this section, we are going to see the operations performed on Complex type Constructors.

Operators Operands Description
array (val1, val2, …) It will create an array with the given elements as mentioned like val1, val2
Create_ union (tag, val1, val2, …) It will create a union type with the values that is being mentioned to by the tag parameter
map (key1, value1, key2, value2, …) It will create a map with the given key/value pairs mentioned in operands
Named_struct (name1, val1, name2, val2, …) It will create a Struct with the given field names and values mentioned in operands
STRUCT (val1, val2, val3, …) Creates a Struct with the given field values. Struct field names will be col1, col2, .

Summary

  • Hive Query Language (HiveQL) is a query language in Apache Hive for processing and analyzing structured data.
  • Hive provides Built-in operators for Data operations to be implemented on the tables present inside Hive warehouse.
  • Types of Built-in Operators in HiveQL are:
  • Relational Operators
  • Arithmetic Operators
  • Logical Operators
  • Operators on Complex types
  • Complex type Constructors
