Autoencoder in TensorFlow with Example

What is Autoencoder in Deep Learning?

An Autoencoder is a tool for learning data coding efficiently in an unsupervised manner. It is a type of artificial neural network that helps you to learn the representation of data sets for dimensionality reduction by training the neural network to ignore the signal noise. It is a great tool for recreating an input.

In simple words, the machine takes, let’s say an image, and can produce a closely related picture. The input in this kind of neural network is unlabelled, meaning the network is capable of learning without supervision. More precisely, the input is encoded by the network to focus only on the most critical feature. This is one of the reasons why autoencoder is popular for dimensionality reduction. Besides, autoencoders can be used to produce generative learning models. For example, the neural network can be trained with a set of faces and then can produce new faces.

How does TensorFlow Autoencoder work?

The purpose of an autoencoder is to produce an approximation of the input by focusing only on the essential features. You may think why not merely learn how to copy and paste the input to produce the output. In fact, an autoencoder is a set of constraints that force the network to learn new ways to represent the data, different from merely copying the output.

A typical autoencoder is defined with an input, an internal representation and an output (an approximation of the input). The learning occurs in the layers attached to the internal representation. In fact, there are two main blocks of layers which look like a traditional neural network. The slight difference is the layer containing the output must be equal to the input. In the diagram below, the original input goes into the first block called the encoder. This internal representation compresses (reduces) the size of the input. In the second block occurs the reconstruction of the input. This is the decoding phase.

The model will update the weights by minimizing the loss function. The model is penalized if the reconstruction output is different from the input.

Concretely, imagine a picture with a size of 50×50 (i.e., 2,500 pixels) and a neural network with just one hidden layer composed of one hundred neurons. The learning is done on a feature map which is twenty-five times smaller than the input. It means the network needs to find a way to reconstruct 2,500 pixels with only a vector of neurons equal to 100.

Stacked Autoencoder Example

In this Autoencoder tutorial, you will learn how to use a stacked autoencoder. The architecture is similar to a traditional neural network. The input goes to a hidden layer in order to be compressed, or reduce its size, and then reaches the reconstruction layers. The objective is to produce an output image as close as possible to the original. The model has to learn a way to achieve its task under a set of constraints, that is, with a lower dimension.

Nowadays, Autoencoders in Deep Learning are mainly used to denoise an image. Imagine an image with scratches; a human is still able to recognize the content. The idea of denoising autoencoder is to add noise to the picture to force the network to learn the pattern behind the data.

The other useful family of Autoencoder Deep Learning is variational autoencoder. This type of network can generate new images. Imagine you train a network with the image of a man; such a network can produce new faces.

The table below places the stacked autoencoder built in this tutorial next to the other families you are likely to meet, so the constraint each one adds is easy to compare.

How to Build an Autoencoder with TensorFlow

In this tutorial, you will learn how to build a stacked autoencoder to reconstruct an image.

You will use the CIFAR-10 dataset which contains 60000 32×32 color images. The Autoencoder dataset is already split between 50000 images for training and 10000 for testing. There are up to ten classes:

• Airplane
• Automobile
• Bird
• Cat
• Deer
• Dog
• Frog
• Horse
• Ship
• Truck

You need to download the images from the CIFAR-10 dataset page and unzip the archive. The folder cifar-10-batches-py contains five batches of data with 10000 images each in a random order.

Before you build and train your model, you need to apply some data processing. You will proceed as follow:

1. Import the data
2. Convert the data to black and white format
3. Append all the batches
4. Construct the training dataset
5. Construct an image visualizer

Version note: the code in this tutorial targets TensorFlow 1.x. On TensorFlow 2 the tf.contrib module no longer exists, and placeholders, sessions and the initializable iterator live under tf.compat.v1. Calling tf.compat.v1.disable_v2_behavior() after the import is the quickest way to run the listings unchanged.

Image preprocessing

Step 1) Import the data

According to the official website, you can upload the data with the following code. The Autoencoder code will load the data in a dictionary with the data and the label. Note that the code is a function.

import numpy as np
import tensorflow as tf
import pickle
def unpickle(file):
    import pickle
    with open(file, 'rb') as fo:
        dict = pickle.load(fo, encoding='latin1')
    return dict

Step 2) Convert the data to black and white format

For simplicity, you will convert the data to a grayscale. That is, with only one dimension against three for colors image. Most of the neural network works only with one dimension input.

def grayscale(im):
    return im.reshape(im.shape[0], 3, 32, 32).mean(1).reshape(im.shape[0], -1)

Step 3) Append all the batches

Now that both functions are created and the dataset loaded, you can write a loop to append the data in memory. If you check carefully, the unzipped file with the data is named data_batch_ with a number from 1 to 5. You can loop over the files and append it to data.

When this step is done, you convert the colour data to a grayscale format. As you can see, the shape of the data is 50000 and 1024. The 32*32 pixels are now flattened to 1024.

# Load the data into memory
data, labels = [], []
## Loop over the b
for i in range(1, 6):
    filename = './cifar-10-batches-py/data_batch_' + str(i)
    open_data = unpickle(filename)
    if len(data) > 0:
        data = np.vstack((data, open_data['data']))
        labels = np.hstack((labels, open_data['labels']))
    else:
        data = open_data['data']
        labels = open_data['labels']

data = grayscale(data)
x = np.matrix(data)
y = np.array(labels)
print(x.shape)
(50000, 1024)

Note: Change ‘./cifar-10-batches-py/data_batch_’ to the actual location of your file. For instance for a Windows machine, the path could be filename = ‘E:\cifar-10-batches-py\data_batch_’ + str(i)

Step 4) Construct the training dataset

To make the training faster and easier, you will train a model on the horse images only. The horses carry label 7 in the label data. As mentioned in the documentation of the CIFAR-10 dataset, each class contains 5000 images. You can print the shape of the data to confirm there are 5,000 images with 1024 columns as shown in the below TensorFlow Autoencoder example step.

horse_i = np.where(y == 7)[0]
horse_x = x[horse_i]
print(np.shape(horse_x))
(5000, 1024)

Step 5) Construct an image visualizer

Finally, you construct a function to plot the images. You will need this function to print the reconstructed image from the autoencoder.

An easy way to print images is to use the imshow() function from the Matplotlib library. Note that, you need to convert the shape of the data from 1024 to 32*32 (i.e. format of an image).

# To plot pretty figures
%matplotlib inline
import matplotlib
import matplotlib.pyplot as plt
def plot_image(image, shape=[32, 32], cmap = "Greys_r"):
    plt.imshow(image.reshape(shape), cmap=cmap,interpolation="nearest")
    plt.axis("off")

The function takes 3 arguments:

• Image: the input
• Shape: list, the dimension of the image
• Cmap: choose the color map. By default, grey

You can try to plot the first image in the dataset. You should see a man on a horse.

plot_image(horse_x[1], shape=[32, 32], cmap = "Greys_r")

The call returns the grayscale thumbnail below, and it confirms the reshape from 1024 values back to a 32×32 image is correct.

Set Dataset Estimator

All right, now that the dataset is ready to use, you can start to use TensorFlow. Before building the model, use the Dataset estimator of TensorFlow to feed the network.

You will build a Dataset with TensorFlow estimator. To refresh your mind, you need to use:

• from_tensor_slices
• repeat
• batch

The full code to build the dataset is:

dataset = tf.data.Dataset.from_tensor_slices(x).repeat().batch(batch_size)

Note that x is a placeholder shaped [None,n_inputs]. The first dimension is set to None because the number of images fed to the network is equal to the batch size, which is only decided at run time. For details, please refer to the tutorial on linear regression with TensorFlow.

After that, you need to create the iterator. Without this line of code, no data will go through the pipeline.

iter = dataset.make_initializable_iterator() # create the iteratorfeatures = iter.get_next()

Now that the pipeline is ready, you can check if the first image is the same as before (i.e., a man on a horse).

You set the batch size to 1 because you only want to feed the dataset with one image. You can see the dimension of the data with print(sess.run(features).shape). It is equal to (1, 1024). The 1 means a single image of 1024 values is fed each time. If the batch size is set to two, then two images will go through the pipeline. Do not change the batch size, otherwise it will throw an error, because only one image at a time can go to the function plot_image().

## Parameters
n_inputs = 32 * 32
BATCH_SIZE = 1
batch_size = tf.placeholder(tf.int64)

# using a placeholder
x = tf.placeholder(tf.float32, shape=[None,n_inputs])
## Dataset
dataset = tf.data.Dataset.from_tensor_slices(x).repeat().batch(batch_size)
iter = dataset.make_initializable_iterator() # create the iterator
features = iter.get_next()

## Print the image
with tf.Session() as sess:
    # feed the placeholder with data
    sess.run(iter.initializer, feed_dict={x: horse_x,
                                         batch_size: BATCH_SIZE})
    print(sess.run(features).shape)
    plot_image(sess.run(features), shape=[32, 32], cmap = "Greys_r")
(1, 1024)

The pipeline returns the same rider that was plotted directly from the NumPy matrix, which proves the placeholder, the iterator and the batch size are wired correctly.

Build the network

It is time to construct the network. You will train a stacked autoencoder, that is, a network with multiple hidden layers.

Your network will have one input layer with 1024 points, i.e., 32×32, the shape of the image.

The encoder block will have one top hidden layer with 300 neurons, a central layer with 150 neurons. The decoder block is symmetric to the encoder. You can visualize the network in the diagram below. Note that you can change the values of hidden and central layers.

Building an autoencoder is very similar to any other deep learning model.

You will construct the model following these steps:

1. Define the parameters
2. Define the layers
3. Define the architecture
4. Define the optimization
5. Run the model
6. Evaluate the model

In the previous section, you learned how to create a pipeline to feed the model, so there is no need to create the dataset once more. You will construct an autoencoder with four layers. You use the Xavier initialization. This is a technique to set the initial weights according to the variance of both the input and output. Finally, you use the ELU activation function. You regularize the loss function with an L2 regularizer.

Step 1) Define the parameters

The first step implies to define the number of neurons in each layer, the learning rate and the hyperparameter of the regularizer.

Before that, you import the partial function. It is a better method to define the parameters of the dense layers. The code below defines the values of the autoencoder architecture. As listed before, the encoder has two layers, with 300 neurons in the first layer and 150 in the second layer. Their values are stored in n_hidden_1 and n_hidden_2.

You need to define the learning rate and the L2 hyperparameter. The values are stored in learning_rate and l2_reg.

from functools import partial

## Encoder
n_hidden_1 = 300
n_hidden_2 = 150  # codings

## Decoder
n_hidden_3 = n_hidden_1
n_outputs = n_inputs

learning_rate = 0.01
l2_reg = 0.0001

The Xavier initialization technique is called with the object xavier_initializer from the estimator contrib. In the same estimator, you can add the regularizer with l2_regularizer.

## Define the Xavier initialization
xav_init =  tf.contrib.layers.xavier_initializer()
## Define the L2 regularizer
l2_regularizer = tf.contrib.layers.l2_regularizer(l2_reg)

Version note: tf.contrib was removed in TensorFlow 2. The direct replacements are tf.keras.initializers.GlorotUniform() for xavier_initializer() and tf.keras.regularizers.l2() for l2_regularizer().

Step 2) Define the layers

All the parameters of the dense layers have been set; you can pack everything in the variable dense_layer by using the object partial. dense_layer then uses the ELU activation, Xavier initialization, and L2 regularization on every call.

## Create the dense layer
dense_layer = partial(tf.layers.dense,
                         activation=tf.nn.elu,
                         kernel_initializer=xav_init,
                         kernel_regularizer=l2_regularizer)

Step 3) Define the architecture

If you look at the diagram of the architecture, you note that the network stacks three layers with an output layer. In the code below, you connect the appropriate layers. For instance, the first layer computes the dot product between the input matrix features and the matrix containing the 300 weights. After the dot product is computed, the output goes to the ELU activation function. The output becomes the input of the next layer, that is why you use it to compute hidden_2 and so on. The matrix multiplication is the same for each layer because you use the same activation function. Note that the last layer, outputs, does not apply an activation function. It makes sense because this is the reconstructed input.

## Make the mat mul
hidden_1 = dense_layer(features, n_hidden_1)
hidden_2 = dense_layer(hidden_1, n_hidden_2)
hidden_3 = dense_layer(hidden_2, n_hidden_3)
outputs = dense_layer(hidden_3, n_outputs, activation=None)

Step 4) Define the optimization

The last step is to construct the optimizer. You use the Mean Square Error as a loss function. If you recall the tutorial on linear regression, you know that the MSE is computed with the difference between the predicted output and the real label. Here, the label is the feature because the model tries to reconstruct the input. Therefore, you want the mean of the sum of the squared difference between predicted output and input. With TensorFlow, you can code the loss function as follow:

loss = tf.reduce_mean(tf.square(outputs - features))

Then, you need to optimize the loss function. You use the Adam optimizer to compute the gradients. The objective function is to minimize the loss.

## Optimize
loss = tf.reduce_mean(tf.square(outputs - features))
optimizer = tf.train.AdamOptimizer(learning_rate)
train  = optimizer.minimize(loss)

One more setting before training the model. You want to use a batch size of 150, that is, feed the pipeline with 150 images each iteration. You need to compute the number of iterations manually. This is trivial to do:

If you want to pass 150 images each time and you know there are 5000 images in the dataset, the number of iterations is equal to 5000 divided by 150. In Python you can run the following codes and make sure the output is 33:

BATCH_SIZE = 150
### Number of batches :  length dataset / batch size
n_batches = horse_x.shape[0] // BATCH_SIZE
print(n_batches)
33

Step 5) Run the model

Last but not least, train the model. You are training the model with 100 epochs. That is, the model will see the images 100 times while optimizing the weights.

You are already familiar with the codes to train a model in TensorFlow. The slight difference is to pipe the data before running the training. In this way, the model trains faster.

You are interested in printing the loss after ten epochs to see if the model is learning something (i.e., the loss is decreasing). The training takes 2 to 5 minutes, depending on your machine hardware.

## Set params
n_epochs = 100

## Call Saver to save the model and re-use it later during evaluation
saver = tf.train.Saver()

with tf.Session() as sess:
    sess.run(tf.global_variables_initializer())
    # initialise iterator with train data
    sess.run(iter.initializer, feed_dict={x: horse_x,
                                          batch_size: BATCH_SIZE})
    print('Training...')
    print(sess.run(features).shape)
    for epoch in range(n_epochs):
        for iteration in range(n_batches):
            sess.run(train)
        if epoch % 10 == 0:
            loss_train = loss.eval()   # not shown
            print("\r{}".format(epoch), "Train MSE:", loss_train)
        #saver.save(sess, "./my_model_all_layers.ckpt")
    save_path = saver.save(sess, "./model.ckpt")
    print("Model saved in path: %s" % save_path)
Training...
(150, 1024)
0 Train MSE: 2934.455
10 Train MSE: 1672.676
20 Train MSE: 1514.709
30 Train MSE: 1404.3118
40 Train MSE: 1425.058
50 Train MSE: 1479.0631
60 Train MSE: 1609.5259
70 Train MSE: 1482.3223
80 Train MSE: 1445.7035
90 Train MSE: 1453.8597
Model saved in path: ./model.ckpt

Step 6) Evaluate the model

Now that you have your model trained, it is time to evaluate it. You need to import the test set from the file /cifar-10-batches-py/.

test_data = unpickle('./cifar-10-batches-py/test_batch')
test_x = grayscale(test_data['data'])
#test_labels = np.array(test_data['labels'])

Note: For a Windows machine, the code becomes test_data = unpickle(r”E:\cifar-10-batches-py\test_batch”)

You can try to print image 13, which is a horse.

plot_image(test_x[13], shape=[32, 32], cmap = "Greys_r")

The plot confirms the test batch loaded correctly and that image 13 belongs to the class the model was trained on.

To evaluate the model, you will use the pixel value of this image and see if the encoder can reconstruct the same image after shrinking it to 1024 pixels. Note that, you define a function to evaluate the model on different pictures. The model should work better only on horses.

The function takes two arguments:

• df: Import the test data
• image_number: indicate what image to import

The function is divided into three parts:

1. Reshape the image to the correct dimension i.e 1, 1024
2. Feed the model with the unseen image, encode/decode the image
3. Print the real and reconstructed image

def reconstruct_image(df, image_number = 1):
    ## Part 1: Reshape the image to the correct dimension i.e 1, 1024
    x_test = df[image_number]
    x_test_1 = x_test.reshape((1, 32*32))

    ## Part 2: Feed the model with the unseen image, encode/decode the image
    with tf.Session() as sess:
        sess.run(tf.global_variables_initializer())
        sess.run(iter.initializer, feed_dict={x: x_test_1,
                                      batch_size: 1})
    ## Part 3:  Print the real and reconstructed image
      # Restore variables from disk.
        saver.restore(sess, "./model.ckpt")
        print("Model restored.")
      # Reconstruct image
        outputs_val = outputs.eval()
        print(outputs_val.shape)
        fig = plt.figure()
      # Plot real
        ax1 = fig.add_subplot(121)
        plot_image(x_test_1, shape=[32, 32], cmap = "Greys_r")
      # Plot estimated
        ax2 = fig.add_subplot(122)
        plot_image(outputs_val, shape=[32, 32], cmap = "Greys_r")
        plt.tight_layout()
        fig = plt.gcf()

Now that the evaluation function is defined, you can have a look at the reconstructed image number thirteen.

reconstruct_image(df =test_x, image_number = 13)

INFO:tensorflow:Restoring parameters from ./model.ckpt
Model restored.
(1, 1024)

The figure places the original test image on the left and the autoencoder output on the right, so the loss of fine detail after the 1024 to 150 compression is easy to judge.
