Prior to Hive installation we require dedicated Hadoop installation, up and running with all the Hadoop daemons.

For Installation of Hadoop check this link

Once all the Hadoop daemons are working fine, just start Hive installation part.

Installation is a 3 step process-

  1. Installation of Hive
  2. Hive shell commands
  3. Install and configure MYSQL database

Installation of Hive

Step 1) Downloading and Installing Hive

For downloading Hive stable version refer Apache URL as mentioned below

http://apache.claz.org/hive/stable/

Installation and Configuration of HIVE and MYSQL

Go to the URL location and Click on the link to download hive tar file.

Step 2) Extracting the tar file.

Go to the downloaded Tar file location ->extract the tar file by using the following command

tar –xvf  apache-hive-1.2.0-bin.tar.gz

Installation and Configuration of HIVE and MYSQL

Step 3) Different Configuration properties to be placed in Hive.

In this step, we are going to do two things

  1. Placing Hive Home path in bashrc file
  2. Placing Hadoop Home path location in hive-config.sh
  1. Mention Hive Pathin ~/.bashrc

Installation and Configuration of HIVE and MYSQL

  • Open the bashrc file as shown in above screenshot
  • Mention Hive home path i.e., HIVE_HOME path in bashrc file and export it as shown in below

Installation and Configuration of HIVE and MYSQL

Code to be placed in bashrc

export HIVE_HOME="/home/guru99hive/apache-hive-1.2.0-bin"
export PATH=$PATH:$HIVE_HOME/bin
  1. Exporting Hadoop path in Hive-config.sh ( To communicate with the Hadoop eco system we are defining Hadoop Home path in hive config field)

    Open the hive-config.sh as shown in below

Installation and Configuration of HIVE and MYSQL

Mention the HADOOP_HOME Path  in hive-config.sh file as shown in below  ( HADOOP_HOME Path)

Installation and Configuration of HIVE and MYSQL

Step 4) Creating Hive directories in Hadoop:

To communicate with Hadoop, we need to create directories in Hadoop as shown below.

Installation and Configuration of HIVE and MYSQL

Giving root permissions to create Hive folders in Hadoop.If it doesn't throw any error message, then it means that Hadoop has successfully given permissions to Hive folders.

Installation and Configuration of HIVE and MYSQL

Step 5) Getting into Hive shell by entering '. /hive' command as shown in below.

Installation and Configuration of HIVE and MYSQL

Hive shell commands

Here we are going to create sample table using Hive shell command "create" with column names.

Sample Code for creating data base in Hive

Installation and Configuration of HIVE and MYSQL

From the above screen shot we can observe the following:

  1. Creation of Sample Table with column names in Hive
  • Here the table name is "product" with three column names product, pname, and price
  • The three column names denoted by their respective data type
  • All fields are terminated by coma ', '
  1. Displaying Hive Table information
  • Using "describe" command we can able to see the table information present in Hive
  • Here it is displaying column names with their respective data types present in table schema
  • At the end, it will display time to perform this command and number of rows it fetched

Sample Code for creating data base in Hive (For self check )

1) Create table product(product int, pname string, price float)

Row format delimited
Fields terminated by ',';

2)describe product:

Install and configure MYSQL database

Why to Use MySQL in Hive as Meta store:

  • By Default, Hive comes with derby database as metastore.
  • Derby database can support only single active user at a time
  • Derby is not recommended in production environment

So the solution here is

  • Use MYSQL as Meta storage at backend to connect multiple users with Hive at a time
  • MYSQL is Best choice for the standalone metastore

Steps to Install and configure MySQL database in Hive on Hadoop

Step 1) In this step, we are going to perform two tasks

  1. Installation of mysql-server
  2. Checking the mysql-server and its process
  1. Using sudo apt-get install mysql-server command, we can download mysql server

Install MySQL as shown in the screenshot

Installation and Configuration of HIVE and MYSQL

  1. After successful installation at end, MySQL will run as shown in below screen shot

Installation and Configuration of HIVE and MYSQL

Step 2) Installing MySQL Java Connector. This is for java dependencies and connection purpose

Installation and Configuration of HIVE and MYSQL

Step 3) Creating soft link for connector in Hive lib directory. This is for soft link between Java and MySql.

Installation and Configuration of HIVE and MYSQL

Step 4) Configuring MySql storage in Hive

Installation and Configuration of HIVE and MYSQL

  • Type MySql –u root –p followed by password
  • Here –u represents root username , p denotes password
  • After entering the above command, the user has to enter valid password and then click enter
  • Then it will enter into MySql shell mode

Step 5) Creating username and password for MySql, granting privileges.

Installation and Configuration of HIVE and MYSQL

We have to execute the commands as shown below,

mysql> CREATE USER 'hiveuser'@'%' IDENTIFIED BY 'hivepassword';
mysql> GRANT all on *.* to 'hiveuser'@localhost identified by 'hivepassword';
mysql>  flush privileges;

Step 6) Configuring hive-site.xml

  • After Step 5 assign username and password to MySQL database and given privileges.
  • Here we will configure some properties in Hive to get a connection with MySQL database.

Installation and Configuration of HIVE and MYSQL

Installation and Configuration of HIVE and MYSQL

From the above screenshot, we observe the following. Here we are defining 4 properties that could be necessary to establish MYSQL as Meta store in Hive

These are as follows:

  1. This property is for connection URL purpose. Here we are defining ConnectionURL in this property. It acts as JDBC connection and its representing metastore location as well
  2. This property is for Connection driver name. Here mysql.jdbc.Driver is the respected value we have to mention in the value tag
  3. This property used for defining Connection User name. In this, we defined "hiveguru" as user name
  4. This property used for mentioning Connection Password. In this, we defined password as user password.

Once the properties placed in hive –site.xml we have to manually save (Ctrl+S) and close the file. After closing this file, we have to create Hive table and check the table details in MySQL storage.

Place this code in hive-site.xml

hive-site.xml

<configuration>
	<property>
		<name>javax.jdo.option.ConnectionURL</name>
		<value>jdbc:mysql://localhost/metastore?createDatabaseIfNotExist=true</value>
		<description>metadata is stored in a MySQL server</description>
	</property>
	<property>
		<name>javax.jdo.option.ConnectionDriverName</name>
		<value>com.mysql.jdbc.Driver</value>
		<description>MySQL JDBC driver class</description>
	</property>
	<property>
		<name>javax.jdo.option.ConnectionUserName</name>
		<value>hiveuser</value>
		<description>user name for connecting to mysql server</description>
	</property>
	<property>
		<name>javax.jdo.option.ConnectionPassword</name>
		<value>hivepassword</value>
		<description>password for connecting to mysql server</description>
	</property>
</configuration>

Step7) Create table "guru99" in Hive.

Installation and Configuration of HIVE and MYSQL

From the above screenshot, we can observe the following

  • Creation of table name"guru99" with two column names
  • The columns names mentioned with its data type as one is integer, and another one is of string type

In the next step, we are going to check whether it is stored in MySql or not

Step 8) Entering into MySql shell mode

Installation and Configuration of HIVE and MYSQL

From the above screenshot, we can observe the following

  • First we have to use the database as "use metastore"
  • Once it chooses meta store we can check the tables present in this by using "show" tables command as shown in the screenshot
  • Whatever the tables that are created in Hive, the metadata corresponds to that tables are stored under TBLS in MySQL database.
  • "Guur99 table" is created in Hive, so the corresponding metadata is stored in MySQL under TBLS.

Step 9) Checking whether created table is presenting MySQL or Not

Installation and Configuration of HIVE and MYSQL

By entering select * from TBLS, it is going to display the tables that we created in Hive shell mode

From the above screenshot we can observe following things:

  • Table name "guru99" that created is the Hive can be displayed in MySQL shell mode
  • Beside this, it will also provide information like table creation time, accessed time and other properties as shown in screen shot above.
